Thursday, October 10, 2019

Teledyne LeCroy offer protocol analysis and jamming PAM4

Teledyne LeCroy is offering a highly integrated Ethernet and Fibre Channel protocol analysis and impairment system.

The SierraNet M648 platform provides traffic capture and manipulation for testing application or link characteristics. It supports examination of Ethernet and Fibre Channel links utilizing both Pulse Amplitude Modulation 4 (PAM4) and legacy Non-Return to Zero (NRZ) technologies.
The SierraNet M648 combines the exceptional Teledyne LeCroy expertise for physical layer testing with triggering, analysis and debug functions for a wide range of current and evolving SAN and LAN specific protocols (i.e. NVMe-oF™, FCoE, iSCSI, and TCP/IP).

https://teledynelecroy.com/protocolanalyzer/fibre-channel/sierranet-m648

Monday, September 9, 2019

Anritsu to show 116-Gbps PAM4 error detector

At the upcoming ECOC 2019 in Ireland later this month, Anritsu will host demonstrations of its new 64,2GBaud NRZ / 58,2GBaud PAM4 Error Detector for the MP1900A Signal Quality Analyzer-R. The analyzer is a high-performance Bit Error Rate Tester (BERT) that accurately measures communications equipment, next-generation high-speed electronic and optical devices, including those for M2M and IoT applications, and optical transceivers used in high-end servers.

The new 64,2GBaud NRZ / 58,2GBaud PAM4 ED card for the MP1900A Signal Quality Analyzer-R is an R&D, high-performance Error Detector supporting signal integrity evaluation on high-speed interfaces. The new ED pluggable card offers switchable NRZ and PAM4 signal analysis, high-accuracy Bit and Symbol Error Ratio measurement, world-beating PAM4 Rx Sensitivity, Clock Recovery and Equalizer.

The  first demonstration will show the new PAM4 Error Detector card combined with the existing high quality PAM4 Pulse Pattern Generator, to prove key capabilities for signal integrity and compliancy testing towards the latest standards in 200G, 400G and 800G transmission, such as MSB/LSB Bit Error Ratio and PAM4 Symbol Error Ratio, up to 58,2G Clock Recovery, 58,2GBaud PAM4 Receiver Sensitivity down to 36mV, Received Signal Equalization to compensate the impact of losses from PCBs and cables.

As an additional unique value in the market, MP1900A multichannel signal generation, combined with 25/50/100/200/400G FEC patterns emulation and jitter tolerance testing, enables accurate evaluation of the true performance of optical transceiver modules in real life working conditions.

In a second joint demonstration with Teledyne-LeCroy, the MP1900A SQA-R Platform, ready for PCIe Gen3, Gen4 and Gen5, will be shown in full automatic calibration, Rx/Tx PCIe Device testing, Link Training verification and Jitter Tolerance validation. The stressed signal calibration will be performed on a Teledyne-LeCroy LabMaster oscilloscope with a single SW tool controlling the whole test system.
https://www.anritsu.com/en-US/test-measurement/news/news-releases/2019/2019-08-28-us02

Thursday, August 22, 2019

Verizon signs Boingo to bring 5G in airports, office buildings, stadiums, etc.

Verizon is working with Boingo Wireless to bring 5G Ultra Wideband service indoors and to public spaces – places like airports, stadiums and arenas, office buildings, hotels, etc.

Boingo is a leading distributed antenna system (DAS), small cells and Wi-Fi provider.

The companies confirmed that they are working together to architect a hyper-dense network designed for large and small indoor spaces as part of Verizon’s ongoing 5G network expansions.

In addition, Verizon announced the expansion of its 5G service to Phoenix, Arizona. Initially, Verizon 5G Ultra Wideband service will be concentrated in Downtown Phoenix around several well-known landmarks, including: Phoenix Convention Center, Talking Stick Resort Arena, The Orpheum Theatre, CityScape, and Chase Field. It will also be available in Tempe, on the Arizona State University campus.


Tuesday, July 23, 2019

VeEX intros 400GE QSFP-DD PAM4 test module

VeEX introduced a dual-port 400GE QSFP-DD PAM4 test module for the MPA® Multi-Protocol Analyzer Series platform.

The new MPM-400AR module provides up to 800G of throughput to address the high capacity testing demands of the PAM4 Ethernet/transport market. The unit supports dual simultaneous and independent 400G QSFP-DD ports along with dual QSFP56 and SFP56 ports, enabling flexible testing capabilities for a wide range of optical transceivers, port and data rates all in the same module.

“At VeEX we strive to provide innovative test solutions and technology support to facilitate the industry’s demanding testing challenges of delivering next-generation products and services. The new MPM-400AR is the result of such commitment,” said Keith Cole, Vice President of Product Marketing, NEMs for VeEX. “Building upon our existing CFP8 test module (MPM-400G) and the first and only 400G handheld test set in the market (RXT-6400), the MPM-400AR raises the bar for native 400G PAM4 testing, in a compact, scalable, yet powerful rack-mount form factor.”

Used in the modular MPA platform with existing 10/100G application modules, the MPM-400AR provides simultaneous, independent, multi-port test capabilities, supporting all common and emerging transceiver form factors, from 400 Gbps to 10 Mbps. Test automation is key for high volume applications and multiple APIs are supported, including native Python, providing NEMs R&D/SVT labs, manufacturing, and service providers with a comprehensive all-in-one toolset for verification of PAM4 Ethernet/transport technologies.

Monday, July 1, 2019

VIAVI supplies 5G equipment validation for Samsung

Samsung Electronics has selected the VIAVI TM500 Network Tester and TeraVM 5G Core Emulator to validate 5G network equipment performance. The partnership marks the first wrap-around testing of 5G stand-alone (SA) base station equipment, and emulating real-world conditions enables end-to-end test of the radio access network (RAN), thereby ensuring performance and reliability in the field.

Viavi's TM500 is a scalable test system for validating network performance as experienced by end users. The solution is in use with almost every base station manufacturer in the industry. Recently released industry-first features include uplink MIMO on two layers; downlink 8CC CA; MIMO support; 4CC uplink and downlink carrier aggregation at 120 kHz and 240 kHz; millimeter wave support; and support for large numbers of UEs on 5G in both Non-Standalone (NSA) and Standalone (SA) modes. In addition to the industry-leading capabilities of the TM500 and TeraVM solutions, VIAVI is known for its long-standing reliability built from years of successful experience and knowledge, technology roadmap and robust local support.


Wednesday, June 19, 2019

Keysight supplies 5G network emulation for Qualcomm's 5G laptop

Qualcomm used Keysight's 5G network emulation solutions to demonstrate the industry’s first 5G laptop with integrated modem at last month's Computex in Taipei.

The demonstration showcased always connected workflows, all-day battery life and Windows 10 support using Qualcomm’s latest platform, the Qualcomm Snapdragon™ 8cx system-on-a-chip (SoC) and X55 5G modem, as well as Keysight’s 5G network emulation solutions. The demo reached downstream speeds of up to 7Gbps.

“We are pleased to again support Qualcomm, and their connected ecosystem of wireless device makers, to deliver 5G applications for consumers and vertical industries,” stated Lucas Hansen, senior director of Keysight's wireless test group. “Keysight’s 5G solutions are rapidly becoming the industry standard across the mobile ecosystem, enabling mobile and device manufacturers to validate multi-mode designs and offer these exciting new products to consumers.”

Keysight’s 5G network emulation solutions – based on Keysight's UXM 5G Wireless Test Platform – enable device makers to validate 5G NR multi-mode designs across protocol, radio frequency (RF) and radio resource management (RRM) in both non-standalone (NSA) and stand-alone (SA) modes.

Earlier this year, the two companies announced they had established the mobile industry’s first announced 5G NR data call in the Frequency Division Duplexing (FDD) mode.

Monday, June 3, 2019

MACOM introduces wideband amplifier for 5G testing

MACOM introduced a new wideband distributed amplifier suited for use in 5G test and measurement (T&M) equipment spanning sub-6 GHz to mmW frequencies.

The new MAAM-011238 amplifier supports wideband operation from 100 kHz up to 50 GHz (67.5 GHz for the Bare-DIE version) with typical gain of 14 dB at 30 GHz.

The amplifier is offered in both bare-DIE and Surface Mount packaged formats.

https://www.macom.com/about/news-and-events/press-release-archive/row-col1/news--event-archive/macom-announces-new-wideband-amp

Wednesday, May 22, 2019

Luna Innovations debuts high-res analyzer for silicon photonics

Luna Innovations introduced its next generation, high-performance, high-resolution analyzer for optical components and networks. The new product extends the optical frequency domain reflectometry (OFDR) platform from Luna Innovations to manufacturing test and quality control applications.

The new Luna 6415 features an integrated tunable laser that provides fast and accurate information at a fraction of the cost of multi-unit test systems. The company says that unlike traditional passive component testers, the Luna 6415 measures and analyzes the Insertion Loss (IL) and Return Loss (RL) distribution, as well as length, working in either reflection or transmission.

“Today’s extreme expansion in communications bandwidth and capacity depends on rapid advancements in fiber optic component and network technology. A high-speed, economical and scalable optical network is the backbone of our communications infrastructure and forms the basis for everything from cloud computing to ultra-fast 5G mobile networking,” Scott Graeff, President and CEO of Luna Innovations, said. “The 6415 gives our customers the power to develop, test and manufacture the next generation optical network components that fuel this global demand for bandwidth.”

https://lunainc.com/product/luna-6415/


Spirent intros NFV test solution

Spirent Communications introduced a test solution for assuring NFV performance as specified in ETSI GS NFV-TST 001.

Spirent CloudSure, which is the first commercially-available standards-based NFV test solution, is designed to benchmark and validate performance and allow service providers to confidently rollout NFV deployments.

Spirent CloudSure offers test packages, consisting of a set of templates that can be easily configured and customized to match service providers’ unique NFV deployments. Configuration is possible via both a graphical user interface (GUI) and an application programming interface (API) for automation users, with Spirent TestCenter Virtual ports and Spirent CloudStress agents generating realistic, multi-dimensional workloads to assess cloud performance.

“Spirent CloudSure takes a new approach to measuring performance of virtualized infrastructure, with a test framework which addresses operators’ key NFV concerns,” said Abhitesh Kastuar, General Manager of Spirent’s Cloud and IP business. “Focused on benchmarking and validating NFV ecosystems in line with ETSI GS NFV-TST 001, Spirent CloudSure is a uniquely flexible and adaptable framework which can also address other cloud testing challenges, such as comparing cloud performance, cloud workload migration, and capacity planning.”

https://www.spirent.com/products/cloudsure

Tuesday, January 15, 2019

SoftBank picks Keysight’s 5G network emulation

SoftBank has chosen Keysight’s 5G network emulation solutions to characterize and validate new 5G New Radio (NR) mobile devices intended to operate on the Japanese mobile operator’s 5G network.

Keysight is supplying its 5G test solutions, including its 5G NR network emulations solutions, based on the UXM 5G platform for radio frequency (RF) performance validation of new 5G mobile devices in over-the-air (OTA) test environments.

"Keysight is pleased to help leading mobile operators like SoftBank meet their strategic goals to commercialize 5G," said Kailash Narayanan, vice president of Keysight’s wireless test group. "Keysight’s industry-leading 5G solutions, expertise in OTA testing, and comprehensive service offerings, combined with our many collaborations with mobile operators and their ecosystems, will significantly accelerate 5G development and deployment globally."

Wednesday, November 28, 2018

Spirent intros WLAN 802.11ax (Wi-Fi 6) test kit

Spirent Communications introduced an WLAN 802.11ax (Wi-Fi 6) testing solution.

The Spirent TestCenter WLAN 802.11ax testing solution can be employed for functionality, feature, and performance testing of IEEE 802.11ax Access Points (APs) and end-to-end testing of WLAN ecosystems, including WLAN access controllers and gateways. It emulates a large number of realistic WLAN clients through both the in-chassis 2.5G/5G Ethernet and 802.11ax Wi-Fi test ports to easily achieve multi-Gbps throughput. The solution also provides complete Dynamic Frequency Selection (DFS) testing coverage through the integration of a radar signal emulation tool, to support both RF cabled conductive testing and Over-The-Air (OTA) testing.

“Users expect Wi-Fi technologies to be ubiquitous. The emergence of these latest enhancements such as Wi-Fi 6 allow network equipment manufacturers, service providers and enterprises to scale up their Wi-Fi access points to carrier-grade and enterprise-grade technology, improving capacity, performance, reliability, and security significantly,” said Spirent’s General Manager of Cloud and IP, Abhitesh Kastuar. “Spirent’s new 802.11ax test solution builds on the market leadership the company established in 802.11ac testing, expanding it to the latest standards in Wi-Fi 6 AP, device, and networking.”

“By leveraging the 802.11ax chipset from Qualcomm Technologies in their test equipment, Spirent empowers the Wi-Fi ecosystem with key testing features to optimize the performance and functionality of their Wi-Fi 6 routers,” said Gopi Sirineni, Vice President, Product Management, Qualcomm Technologies, Inc. “We are pleased to be working alongside Spirent and WLAN Access Point vendors to encourage the adoption of Wi-Fi 6 technology – delivering significant upgrades to the capacity and efficiency of traditional broadband networks to better meet the demands of modern consumers.”

https://www.spirent.com/Products/WLAN-Test-Solutions

Saturday, November 24, 2018

Anritsu releases 400GbE PAM4 BER Test

Anritsu announced the commercial release of its 64-Gbaud PAM4 Pulse Pattern Generator (PPG) and 32-Gbaud PAM4 Error Detector (ED) for use in 400GbE testing.

The new PAM4 BERT modules can be installed in the Anritsu Signal Quality Analyzer-R MP1900A series to implement a bit-error-rate test solution using either the 26.5625 Gbaud PAM4 x 8 lanes or 53.125- Gbaud PAM4 x 4 lanes methods. When using the PAM4 method to encode data as four amplitude levels, the gap between signal levels is one-third compared to the NRZ method, which reduces the unit time per symbol at higher baud rates, emphasizing the importance of signal quality in achieving high-speed transmissions.

Wednesday, November 14, 2018

VIAVI debuts large-scale 5G Base Station Analyzer

Viavi Solutions introduced its CellAdvisor 5G base station analyzer for use by mobile service providers globally for validating and troubleshooting 5G radio access.

The principal test functions of the CellAdvisor 5G include:

Real-time spectrum and interference analysis with persistence display for FR1 and FR2
5G carrier scanner measuring carrier power up to eight wide-band carriers’ power as well as strongest beam power level and its corresponding identifier (ID)
5G beam analyzer assessing individual beams’ IDs, their power levels and corresponding signal to noise ratios
5G route map for coverage verification mapping, in real-time, the physical cell identity (PCI) and its associated beam ID together with beam strength, as well as making coverage data available for post-processing.

Key features include: support for beamforming analysis, massive MIMO and carrier aggregation; spectrum and interference analysis in Frequency Region 1 (FR1, sub-6 GHz) and Frequency Region 2 (FR2, millimeter wave); flexibility to support wider channel bandwidth configurations (5 MHz to 100 MHz in FR1, and 100 MHz to 400 MHz in FR2); touchscreen functionality; and cloud-based asset and configuration management via the StrataSync platform.

“VIAVI has taken an early lead in 5G testing, and continues to expand its investments,” said Kevin Oliver, Vice President and General Manager, Converged Instruments and Virtual Test, VIAVI. “Virtually every 5G base station in the field today has been verified in the lab using VIAVI instruments and systems. Now, as a number of leading carriers are moving from the lab to large-scale field deployments, CellAdvisor 5G will be the fundamental tool that technicians and contractors will need to install and maintain these 5G deployments.”

http://www.viavisolutions.com

Thursday, September 27, 2018

ECOC 2018: Tektronix shows PAM4 test and debug solutions

At ECOC 2018, Tektronix showcased its optical test solutions, including:
  • PAM 4 Testing - DSA8300 sampling oscilloscope with an 80GHz optical sampling module showing support for IEEE 802.3bs based 400G optical testing for TDECQ, including new advances in high-sensitivity single-mode/multi-mode optical measurements for NRZ and PAM-4.
  • PAM 4 design and debug- DPO70000SX 70GHz ATI performance oscilloscope analyze single shot PAM-4 signals with live triggering and post-equalized error detection for 400G standards.
  • Complex Coherent testing - an end-to-end demonstration of optical modulation analysis software supporting multi-OMA systems, featuring the AWG70000 Series Arbitrary Waveform Generator and the DPO70000SX oscilloscope for applications such as spatial division multiplexing and more.
  • Support for new emerging standards - 400G ZR Receiver Testing - featuring the Tektronix DPO70000SX 70GHz ATI performance oscilloscope


Tuesday, September 25, 2018

Keysight intros 5G Base Station manufacturing test solution

Keysight Technologies introduced a compact and scalable 5G base station manufacturing test solution that enables network equipment manufacturers (NEMs) to streamline volume test of 5G New Radio (NR) infrastructure equipment.

The Keysight S9100A 5G multi-band vector transceiver (S9100A) uses common hardware and software platforms (including Keysight's PathWave) which support the latest 3GPP 5G NR Rel. 15.2.0 standards.  It also uses Keysight's new PXIe vector transceiver (VXT) (Keysight M9410A) to provide industry-leading RF performance in a compact modular design, for improved efficiency and scalability in manufacturing test. Keysight's VXT offers wide bandwidth support of up to 1.2 GHz, combined with high-performance mmWave transceiver heads, to deliver Error Vector Magnitude (EVM) and Adjacent Channel Leakage Ratio (ACLR) performance across FR1 and FR2 in a small footprint.

"The introduction of Keysight's 5G base station manufacturing test solution enables network equipment manufacturers around the world to ramp up 5G manufacturing," said Giampaolo Tardioli, vice president of Keysight's Network Access group. "The scalability across sub-6GHz and mmWave frequencies, compact design and superior RF performance of the S9100A, offer users a clear and rapid path from design validation to volume manufacturing."

Monday, September 17, 2018

NETSCOUT sells off its handset test division

Netscout Systems has divested its handheld network test (HNT) tools business to StoneCalibre, a private equity firm based in Los Angeles. Financial terms were not disclosed.

The HNT portfolio acquired by StoneCalibre includes the LinkSprinter Network Tester, LinkRunner Network Auto-Tester, OneTouch AT Network Assistant, AirCheck G2 Wireless Tester, and AirMagnet Mobile solutions.

NETSCOUT will work toward a smooth transition for customers, partners, contractors and suppliers by collaborating with StoneCalibre to provide a variety of services across a range of functional areas over the next several months as StoneCalibre completes its carve-out of HNT as a standalone company in its portfolio.

Wednesday, September 12, 2018

Keysight supplies 5G network emulation to Motorola Mobility

Keysight Technologies is supplying its 5G network emulation solutions to Motorola Mobility for early 5G chipset prototyping, development, and device design validation.

“We are very pleased to be working with Motorola Mobility to help them bring their latest 5G devices to market faster,” said Scott Bryden, vice president of wireless device solutions at Keysight Technologies. “Early engagements with key 5G chipset providers has enabled Keysight to deliver first-to-market 5G solutions as 5G device design work accelerates.”

Last year, Keysight was first to announce that its suite of 5G network emulation solutions, including 5G Protocol R&D and RF Design Verification Toolsets, support the new 3GPP 5G NR Non-Standalone standard, enabling the device ecosystem to streamline its product workflow from early prototyping and development to design validation and manufacturing.

Sunday, September 9, 2018

Keysight supplies 5G NR Device Dev + Verification to ASUS

Keysight Technologies has supplied its 5G network emulation solutions to accelerate 5G New Radio (NR) device development and verification to ASUS.

ASUS is using Keysight’s 5G network emulation solutions to validate new designs that support the latest 3GPP 5G New Radio (NR) Release 15 specifications, including beamforming and beam management technologies across both sub-6GHz and mmWave frequencies.

Keysight offers end-to-end over-the-air (OTA) testing capabilities by combining its network emulation solutions with customizable chambers for radiated testing. ASUS will use the Compact Antenna Test Range chamber, which has been approved by 3GPP, as an indirect far field test methodology. This chamber will be used to perform device characterization and validation under real-world conditions.

Thursday, September 6, 2018

Anritsu adds 53 Gbaud upgrade for PAM4 optical signal analysis

Anritsu has released new firmware downloads for the BERTWave MP2110A Sampling Oscilloscope that boosts its PAM4 analysis function from 26 Gbaud to 53 Gbaud for the production and inspection of optical modules.

Anritsu notes that current optical modules such as CFP8s use 26-Gbaud PAM4 optical signals, while future mass-produced QSFP-DD and OSFP modules will use 53-Gbaud PAM4 optical signals. Its solution can be used to support the development and production-line inspection of next-generation QSFP-DD optical transceivers expected to be deployed in data centers.

The BERTWave MP2110A is an all-in-one measuring instrument with built-in multi-channel Bit Error Rate Tester (BERT) and Sampling Oscilloscope, supporting bit error rate (BER) measurements, Eye Mask tests, Eye pattern analyses, high sampling speed of 250 kSample/s and low-noise (3.4 μW) high-sensitivity O/E interface. The BERT and Sampling Oscilloscope are required instruments for evaluating optical modules used by optical communications systems.

As well as NRZ technology, the MP2110A also supports PAM4 signal measurements including TDECQ, which enable all-in-one quality evaluations of optical modules at speeds from 25 to 400 G. In addition, the MP2110A, thanks to its high-speed measurement and PAM4 analysis, will play a key role in improving optical module production-line productivity. Moreover, adding 53 Gbaud support for quality evaluation of next-generation optical modules helps cut capital equipment renewal costs.


Thursday, August 9, 2018

Teledyne LeCroy's Protocol Analyzer adds PAM4 50G-400G Ethernet

Teledyne LeCroy introduced a trace capture and analysis solution for the 802.3cd and 802.3bs 50/100/200/400GE four-level pulse amplitude modulation (PAM4) Ethernet specifications.

The new capability, which is available as a license for the company's SierraNet T328 protocol analyzer, enables higher data rates and enhanced reliability for future-generation data centers and cloud-based services.

Teledyne LeCroy notes that PAM4 signals are more susceptible to errors in noisy environments. To reduce the error rate, systems negotiate transmission parameters that maximize signal quality at the receiver. PAM4 Systems designers are demanding the link-layer analysis capabilities to ensure the negotiation among components is effective.

The SierraNet T328 can now help identify and reduce link-interoperability problems between major fabric components such as switches, routers, network interface adapters, servers, and Network Attached Storage (NAS).

"By providing real-time trace capture, decode, and analysis of the auto-negotiation and link-training functions, the SierraNet T328 has become the de facto standard for high-speed protocol analysis in development, debug, and test applications," stated David J. Rodgers, Ethernet and SAN Product Line Manager at Teledyne LeCroy.
