Wednesday, April 7, 2021

Semtech expands 5G front haul portfolio with 50Gbps CDR

Semtech announced sampling of the newest member of its Tri-Edge CDR portfolio, the GN2256, an IC solution to enable 50Gbps PAM4 Fixed-WDM (Wavelength Division Multiplexing), Tunable WDM and Silicon Photonics optical modules.

The device integrates Semtech’s proven Tri-Edge CDR platform with a differential EML (Externally Modulated Laser) driver.

Semtech says the approach to expanding 5G wireless infrastructure bandwidth differs based on geographic region, deployment area considerations and carrier preferences. This often requires different types of optical modules in 5G wireless front haul links. In regions where it is typically difficult to install more fiber or reduce overhead costs, carriers utilize “colored” optical modules that send and receive multiple signals using differing wavelengths on a single fiber. These optical modules are also referred to as WDM optical modules and are critical for the 5G wireless infrastructure, especially for countries like Japan, Korea and the U.S.

The GN2256 combines Semtech’s proprietary analog Tri-Edge technology with enhanced laser driver compensation to enable IEEE and Open Eye MSA compliant optical modules over industrial temperature ranges. Semtech’s Tri-Edge 5G platform addresses the full range of optical modules needed for all regions by enabling multiple types of SFP56 optical modules operating at 50Gbps PAM4.

“With the introduction of the GN2256 Tri-Edge IC, Semtech has established itself as the leader in 5G wireless front haul deployments with a truly differentiated and comprehensive IC portfolio. Semtech is a one-stop shop for our optical module partners and system vendors to enable worldwide 5G wireless front haul deployments,” said Raza Khan, senior market manager for Semtech’s Signal Integrity Products Group.

http://www.semtech.com/optical

Tuesday, February 23, 2021

Semtech samples CDR for 50 Gbps PAM4 front haul

Semtech is now sampling its new Tri-Edge CDR to emerging 50Gbps PAM4 5G front haul deployments.

The new solution (GN2255), which is based on the company's existing Tri-Edge CDR platform qualified in data center applications, offers the small footprint, low power, ultra-low latency, and performance required by 5G front haul applications.

Semtech’s new integrated circuit (IC) enables 50Gbps PAM4 links that will double the bandwidth of currently deployed 25Gbps NRZ front haul links. The IC combines Semtech’s proprietary analog Tri-Edge technology with enhanced laser driver compensation to enable IEEE-compliant optical modules over industrial temperature ranges.

The GN2255 Tri-Edge IC is the industry’s first analog IC solution enabling ultra-low latency, less than 1.5W module power and industry leading performance for up to 10km reach for 50Gbps PAM4 SFP56 optical modules. Semtech’s Tri-Edge technology and proprietary DML compensation will enable use of high volume, low cost 25Gbps bandwidth optics to operate at 50Gbps PAM4.

“Semtech is at the forefront of innovation with this new Tri-Edge IC and we look forward to collaborating with system vendors and our optical module partners to enable next-generation 5G wireless front haul deployments,” said Raza Khan, Senior Market Manager for Semtech’s Signal Integrity Products Group.

https://www.semtech.com/company/press/semtech-to-enable-50gbps-pam4-front-haul-5g-wireless-deployment-with-industrys-first-5g-front-haul-tri-edge-cdr-ic-solution


Monday, September 21, 2020

Amazon Sidewalk envisions a shared network for neighborhoods

 Amazon is advancing its plans for Sidewalk, a crowd-sourced network of consumer devices to be operated by Amazon at no charge to customers. The idea is to leverage the connectivity of devices throughout a neighborhood to help simplify new device setup, extend the low-bandwidth working range of devices, and help devices stay online even if they are outside the range of their home WiFi.

Amazon envisions that its network of Sidewalk-enabled devices could help its device users to find lost pets or valuables, to enable smart security and lighting, or to provide diagnostics for appliances and tools that lose their primary connectivity. Other applications for Sidewalk could include sensors for tracking packages, lost/stolen items, smart irrigation, etc

The Amazon Sidewalk network will be enabled by customers with a Sidewalk Bridge, which is a capability that Amazon has already built into many existing Echo devices, Ring Floodlight Cams and Ring Spotlight Cams. The owners of these devices will be asked to contribute a small portion of their Internet bandwidth.  Amazon will then pool together this connectivity to create a shared network that benefits all Sidewalk-enabled devices in a community. Information traveling over the Sidewalk network will be encrypted. Amazon also promises to cap the maximum bandwidth used by a Sidewalk bridge owner.

Amazon Sidewalk uses Bluetooth Low Energy (BLE), the 900 MHz spectrum and other frequencies to extend coverage.

Semtech confirmed that it is working with Amazon to bring its long-range, low power LoRa platform to the Sidewalk network.

Amazon is also working with Nordic Semiconductor, Silicon Labs and Texas Instruments to enable chip sets that will power new devices.

https://www.amazon.com/Amazon-Sidewalk/b/?node=21328123011

https://www.semtech.com/lora

Thursday, September 10, 2020

Semtech samples 5G CDR with single-ended EML laser driver

 Semtech has begun sampling its new ClearEdge Clock and Data Recovery (CDR) IC, which integrates a single-ended EML laser driver optimized to enable the use of alternative optics for 5G. The company claims its platform offers the lowest power and smallest package size for SFP28 LAN-WDM (LWDM) optical modules.

Semtech’s ClearEdge (GN2154) IC enables industry-leading performance in LWDM modules with low cost EML lasers, while offering ultra-low power of 550mW typical (with 1.85VppSE driver swing) in a small 3.24mm x 2.05mm WLCSP package.

Semtech’s ClearEdge CDR and FiberEdge PMD platform for 5G applications includes:

  • 25G SFP28 300m LR-lite, LR 10km, BiDi, CWDM, MWDM optical modules
  • GN2152: Bi-directional 24-28G ClearEdge CDR with Integrated DML driver
  • GN1086: Next generation 24-28G FiberEdge TIA
  • 25G SFP28 LWDM optical modules
  • GN2154: Bi-directional 24-28G ClearEdge CDR with Integrated SE EML driver
  • GN1086: Next generation 24-28G FiberEdge TIA
  • 25G SFP28 DWDM, Tunable optical modules
  • GN2146: Bi-directional 24-28G ClearEdge CDR with Integrated EML / MZM driver
  • GN1086: Next generation 24-28G FiberEdge TIA

“Semtech has worked closely with its customers and laser partners to understand the challenges of developing an effective solution for LWDM optical transceiver modules and we believe this is a truly disruptive solution in this space,” said Raza Khan, Senior Market Manager for Semtech’s Signal Integrity Products Group. “Semtech offers a broad and unique portfolio to enable complete 5G wireless solutions with an extensive range of module requirements. We expect to continue leading the 5G wireless market with innovative IC offerings.”


Wednesday, March 11, 2020

Semtech releases PAM4 CDR Platform for 200G and 400G

Semtech announced production availability of its "Tri-Edge" CDR SR solutions to enable next-generation data center multi-mode interconnectivity. There are two new devices:

  • GN2558 is a quad PAM4 CDR with an integrated VCSEL driver
  • GN2559 is a quad PAM4 CDR with an integrated linear transimpedance amplifier (TIA).

The GN2558 CDR includes proprietary VCSEL compensation to enable a wide range of VCSEL options with fully adaptive input equalization and fast startup to streamline system bring up. The GN2559 linear TIA and CDR provides superior receiver performance with fast adaptation and startup. The GN2559 includes configurable output equalization enabling robust electrical interfaces.

“Semtech has successfully demonstrated the inter-working of its chipset solution on 400G ports for commercial Ethernet switches over 70m of OM3 fiber and 100m of OM4 fiber,” said Julius Yam, Senior Product Line Manager in Semtech’s Signal Integrity Products Group. “The GN2558 and GN2559 ICs provide the highly desired low power, low latency analog solution to meet the needs of high-performance computing (HPC), artificial intelligence (AI) and Cloud data center networks. This chipset is also fully compliant to the 200G-SR4 Open Eye MSA specification.”

http://www.semtech.com/optical

Tuesday, January 28, 2020

Semtech debuts LoRa transceiver for Smart Home IoT sensors

Semtech introduced a transceiver designed for battery-powered LPWAN based smart home, community and consumer applications. The new Semtech LoRa Smart Home transceiver provides low power, broad coverage for indoor and neighborhood area IoT devices connecting to sensors and actuators for safety, environmental and convenience use cases. The company said its design will power sensors with multi-year operation. It features 600nA of sleep current and 4.6 mA of active receive current consumption.

Key Product Features of LoRa Smart Home (LLCC68)

  • High sensitivity to -126 dBm
  • +22 dBm output power with high efficiency PA
  • System works well even when the signal is 10dB below noise
  • Minimal external BOM/matching
  • Small size foot print, 24-pin 4x4
  • Works with existing LoRaWAN-based gateways
  • <5 consumption="" current="" li="" ma="" rx="">
  • 25 mA TX @ +14dBm
  • Integrated DC-DC and LDO
  • Supports LoRaWAN and other protocols

“With its simple and flexible network architecture, Semtech’s new LoRa® Smart Home device offers a unique opportunity to accelerate the consumer adoption of smart home connected solutions. As an end-to-end solution, or as a complement to Wi-Fi, LoRa Smart Home broadens smart home solutions by enabling connectivity for low cost and battery powered end points both indoors and outdoors,” said Pedro Pachuca, Director of IoT Wireless in Semtech’s Wireless and Sensing Products Group. “The new LoRa Smart Home device provides a flexible and cost effective solution for low latency smart home applications, including smart key locks and lighting, enabling low cost network extension and providing a bridge to the many LoRaWAN®-based B2B and B2C solutions available in the IoT market today.”

Wednesday, December 4, 2019

Semtech enters production shipments of 5G front haul

Semtech announced volume shipments of ClearEdge CDR platform for 5G front haul.

Current 5G wireless deployments (phase 1) utilize 25 Gbps optical links in front haul supported by Semtech’s complete ClearEdge CDR platform.

Semtech says future deployments of 5G will utilize 50 Gbps PAM4 optical links starting in late 2020 enabled by Semtech’s Tri-Edge CDR portfolio.

Semtech’s 5G wireless ClearEdge CDR Platform includes:

  • GN2139C: Bi-directional 24-26G ClearEdge CDR
  • GN2142: Bi-directional 24-28G ClearEdge CDR with Integrated DML driver
  • GN2146: Bi-directional 24-28G ClearEdge CDR with Integrated EML / MZM driver
  • GN2148: Single 24-28G ClearEdge CDR with Integrated VCSEL Driver
  • GN2149: Single 24-28G ClearEdge CDR with Integrated TIA
  • GN1081: 24-28G FiberEdge™ TIA
  • GN1086: Next generation 24-28G FiberEdge TIA

“Semtech continues to make great inroads with the 5G wireless business as we enable our customers’ next generation 5G wireless optical module designs. Volume shipments of our complete front haul chipset platform starting in the fourth calendar quarter of 2019 will enable millions of ports in the coming year. Our customers continue to prioritize our designs based on our performance, delivery and support,” said Raza Khan, Senior Market Manager for Semtech’s Signal Integrity Products Group. “In addition, Semtech is already leading the way to enable analog PAM4-based solutions in the data center market and creating a complete analog PAM4 ecosystem with the Open Eye MSA. Semtech will leverage this PAM4 leadership and enable a complete 5G wireless Tri-Edge CDR portfolio.”

Wednesday, October 2, 2019

Semtech designs indoor LoRa Corecell gateway

Semtech released its LoRa Corecell reference design for indoor gateway applications. The reference design is developed to the LoRaWAN protocol and targeted for home, building and factory automations.

Key features of the LoRa-based Gateway Baseband Transceiver (SX1302):

  • LoRaWAN Class A/B/C, all regions
  • 125 kHz LoRa reception with:
  • 8 x 8 channels LoRa packet detectors
  • 8 x SF5-SF12 LoRa demodulators
  • 8 x SF5-SF10 LoRa demodulators
  • 125 /250 / 500 kHz LoRa demodulator
  • (G)FSK demodulator
  • Direct interface to Semtech transceivers


Multi-band Sub-GHz Radio Frequency Front End (SX1250):

  • +22dBm Output power
  • Lower UHF bands 169 and 433 or 490 MHz
  • North America 915 MHz
  • Europe 868 MHz
  • 24 QFN (4mmx4mm)

“The LoRa Corecell reference design’s key features, including low power, smaller package and higher integration with improved performance, aim to eliminate design complexity and accelerate time-to-market in the smart home and building industries,” said Pedro Pachuca, Director of IoT for Semtech’s Wireless and Sensing Products Group. “As we announced earlier this year, Semtech is committed to developing a LoRa product roadmap that simplifies Internet of Things (IoT) applications that enable a faster time-to-market for IoT solution providers and systems integrators. This new reference design is key to our LoRa offerings as more real estate and commercial managers, as well as consumers, look for solutions that solve their daily challenges, such as meeting room occupancy and temperature/humidity monitoring.”

https://www.semtech.com/company/press/semtech-releases-indoor-reference-design-for-smart-buildings-and-homes

Tuesday, September 24, 2019

Semtech announces 56GB EML driver

Semtech announced its new FiberEdge linear electro-absorption modulated lasers (EML) driver suited for new PAM4-based Ethernet optical modules, including 100G-FR, 400G-DR4 and 400G-FR4.

Semtech's FiberEdge linear EML driver (GN1862) is a bare die single-ended driver specifically designed to provide the performance to power ratio required by hyperscale data center operators. The driver delivers two volts of single-ended swing while minimizing total harmonic distortion (THD) and group delay (GD) to increase module manufacturing yield, thereby driving down costs. As a bare die device, the new FiberEdge solution is ideal for both single channel (100G) and quad channel (400G) PAM4 applications.

“Over the past months, data center architects have discovered that the key to successful 100G per lambda deployments is performance,” said Dr. Timothy Vang, Vice President of Marketing and Applications for Semtech’s Signal Integrity Products Group. “The GN1862 EML driver delivers enough margin to specifications to enable modules with up to 40km reach.”

GN1862 is in pre-production with full production expected in December 2019.

http://www.semtech.com/optical

Tuesday, September 3, 2019

Semtech debuts XGSPON chipset

Semtech announced production availability of itsGN7153B combo chip and GN7055B multi-rate burst mode transimpedance amplifier (TIA) for XGSPON Optical Line Terminals (OLTs).

Semtech's GN7153B is a combo chip supporting OLT transmit and receive signals in a fully integrated solution.

On the receive side, the GN7153B supports both XGPON (2.5G) and XGSPON (2.5G/10G) signals, while the transmit data path features Semtech’s 10G EML driver with ClearEdge CDR technology to effectively reset the signal jitter budget. Transmit path optimization can be accomplished through an I2C programmable PLL loop bandwidth control and a variety of jitter filter modes. The EML driver includes eye-shaping features and an Automatic Power Control (APC) loop to deliver best-in-class transmit eye quality. The burst mode receive data path includes a multi-rate 2.5G/10G limiting amplifier with a fast burst mode signal detect function, integrated discharge circuit and reset for short settling time.

Semtech said its high sensitivity burst mode TIA (GN7055B) is designed for XGSPON OLT applications. Using an external reset signal, the burst mode TIA meets the convergence time and burst dynamic range requirements of XGSPON 2.5G and 10G.The device features a fast Automatic Gain Control (AGC) loop to enable high dynamic range in burst mode applications. The GN7055B is offered in die form, supports industrial temperature range and uses a single 3.3V power supply.

“XGSPON will bring a new generation of faster optical broadband services for home and business to the largest sector of the PON market,” said Dr. Timothy Vang, Vice President of Marketing and Applications for Semtech’s Signal Integrity Products Group. “Our chipset contributes to that growth by bringing high performance and low cost.”

http://www.semtech.com/optical

Thursday, March 7, 2019

Semtech expands its EPON portfolio

Semtech introduced a combo chip and a multi-rate burst mode Transimpedance Amplifier (TIA) for 10G EPON Optical Line Terminals (OLTs).

“The upsurge in the 10G EPON market is expected to continue and we believe these products will help drive this growth,” said Dr. Timothy Vang, Vice President of Marketing and Applications for Semtech’s Signal Integrity Products Group. “Our engineering team has produced another unique chipset that delivers higher performance and enables lower manufacturing costs through further integration.”

The combo chip is a fully bidirectional device that supports both 1G and 10G EPON. The transmit data path features Semtech’s 10G EML driver with ClearEdge CDR referenceless technology to effectively reset the path jitter budget. Tx path optimization can be accomplished via an I2C programmable PLL loop bandwidth control and a variety of jitter filter modes. The EML driver includes eye-shaping features and an automatic power control loop to deliver best-in-class transmit eye quality. The burst mode receive data path includes two separate limiting amplifiers, one for 1G EPON and the other for 10G EPON with a fast Burst Mode Signal Detect function. The Rx path outputs 10G data at CML levels, while the 1G Rx output is available at CML or LVPECL levels depending on the device version.

Semtech’s high sensitivity Burst Mode TIA is designed for 10G EPON OLT applications. The device features a fast automatic gain control loop to enable high dynamic range in burst mode applications. The GN7056 is offered in die form, supports industrial temperature range and uses a single 3.3V power supply.

Thursday, September 20, 2018

ECOC 2018: Semtech exhibits CDR platform for 25G SFP28 SR modules and AOCs

At ECOC 2018, Semtech will highlight multiple products including its ClearEdge CDR platform for low-cost 25G SFP28 SR modules and Active Optical Cables.

Semtech will also feature its laser drivers, limiting amplifiers, ROSAs, signal conditioners, transceivers, and transimpedance amplifiers (TIAs).

Semtech supplies high-speed optical transceiver ICs and offers optical networking solutions that support multiple next-generation PAM4 and NRZ connectivity standards including Ethernet, PON, Optical Transport Network (OTN), Fibre Channel, and InfiniBand.

Tuesday, September 4, 2018

Semtech samples PAM4 clock and data recovery platform

Semtech announced sampling of its quad Tri-Edge clock and data recovery (CDR) with an integrated vertical-cavity surface-emitting laser (VCSEL) driver and its quad Tri-Edge CDR with an integrated transimpedance amplifier (TIA).

The bundle is optimized for low power and low cost PAM4 short-reach, 200G/400G QSFP28 SR4/8 modules for data center and active optical cable (AOC) applications.

“With this Tri-Edge PAM4 CDR bundle, Semtech further demonstrates its innovative and disruptive solutions to alternatives available in the market today. We expect this to enable the next-gen deployment for data centers to allow higher bandwidth growth while supporting an aggressive cost structure,” said Dr. Timothy Vang, Vice President of Marketing and Applications for Semtech’s Signal Integrity Products Group.

Semtech also announced:
  • the full production of its ClearEdge CDR platform IC bundle targeting high-performance data center and wireless applications. The quad ClearEdge CDR with integrated DML laser driver and quad ClearEdge CDR with integrated transimpedance amplifier (TIA) provides an optimized chipset for 100G PSM4 and CWDM4 module solutions. The quad ClearEdge CDR with integrated DML laser driver also supports module designs based on both chip-on-board optics and passive TOSAs.
  • initial production of its bi-directional ClearEdge CDR with integrated DML laser driver.
  • mass production of a fully integrated quad 28G ClearEdge CDR with single-ended electro-absorption modulated lasers (EML) laser driver, consuming only 790 mW at maximum, 1.5 Vppse swing, in a 6mm x 5mm package with integrated bias-T passive components. This addresses the challenge of shrinking real estate in QSFP28 designs.

Tuesday, May 29, 2018

Semtech announces PAM4 clock and data recovery platform

Semtech announced a PAM4 clock and data recovery (CDR) platform optimized for low power and low-cost PAM4 optical interconnects used in data center and active optical cable (AOC) applications.

Semtech's Tri-Edge is a new CDR platform technology being developed for the PAM4 communication protocol. It builds on the success of Semtech’s ClearEdge NRZ-based CDR platform technology and extends it to PAM4 signaling.

The company says its Tri-Edge CDR platform will be applicable for 100G, 200G and 400G requirements.

“The rapidly growing demand for bandwidth in the data center market requires a disruptive solution to meet the power, density and cost requirements. By combining leading-edge technologies with a focused application, we can enable a disruptive solution that we believe will meet the needs of the data centers in both the near-term and long-term,” said Imran Sherazi, Vice President of Marketing and Applications for Semtech’s Signal Integrity Products Group.

Semtech notes that its ClearEdge CDRs are the world’s most widely selected optical transceiver CDRs for use in 10G applications and 100G data center applications.


Thursday, March 24, 2016

Semtech Releases Quad 25Gbps Chipset for 100G SR4

Semtech released a new chipset for quad channel 100G-SR4 optical interconnects operating at 25.78 Gbps.

The GN2108 is a quad channel CDR with integrated vertical cavity surface emitting laser (VCSEL) drivers, and the GN2109 is a quad channel CDR with integrated transimpedance amplifiers (TIAs). A full suite of on-chip features minimizes external components and helps customers speed up their hardware and firmware development.

Semtech said its GN2108 VCSEL driver was architected to compensate for optical distortion introduced by VCSELs, enabling extended reach well beyond the SR4 standard to greater than 300m over OM4 fiber, operation with lower bandwidth and lower cost VCSELs, as well as operation with lower VCSEL bias settings for lower power and higher VCSEL reliability.

“The GN2108 and GN2109 chipset has strong traction with our customers,” said Dr. Timothy Vang, Senior Director of Datacom Marketing for Semtech’s Signal Integrity Product Group. “The performance and feature set of the GN2108 and GN2109 is enabling our customers to quickly bring to market winning solutions for 100Gbps QSFP28 and Active Optical Cables (AOCs) for datacenters and a wide range of other applications.”
