Sunday, June 13, 2021

Hengtong Rockley demos 800G QSFP-DD800 DR8 pluggable

Hengtong Rockley Technology Co. announced an 800G QSFP-DD800 DR8 optical module based on EML technology.

There are two main form factors for 800G MSA: OSFP and QSFP-DD800. Because of the tight space, QSFP-DD800 module design has been considered as the most challenging, in term of layout, signal integrity and thermal management.

Hengtong Rockley is adapting 7nm DSP with built-in drivers, and COB structure to achieve this 800G QSFP-DD800 DR8 design, the total module power consumption is around 16W. Sampling is expected later hits year and commercial production is expected in the second half of 2022. Hengtong Rockley also plans to have 800G optical module based on Silicon Photonics technology in 2022.

Hengtong Rockley Technology Co.is a joint venture established by Hengtong Optic-Electric Co., Ltd., China and Rockley Photonics Limited, UK. Hengtong Rockley is based in Suzhou, China.


Thursday, June 10, 2021

NeoPhotonics ships QSFP-DD and OSFP 400ZR coherent modules

NeoPhotonics announced the general availability of its QSFP-DD and OSFP 400ZR pluggable modules.

These products utilize NeoPhotonics Silicon Photonics Coherent Optical Subassembly (COSA) and low power consumption, ultra-narrow linewidth Nano-ITLA tunable laser, combined with the latest generation of 7 nm node DSP, to provide full 400ZR transmission in a standard data center QSFP-DD or OSFP form factor that can be plugged directly into switches and routers.

NeoPhotonics QSFP-DD and OSFP modules have completed reliability qualification and have passed 2000 hours of High Temperature Operating Life (HTOL) as well as other critical tests per Telcordia requirements.

The company recently announced that it had used its QSFP-DD coherent pluggable transceiver to transmit at a 400 Gbps data rate over a distance of 800 km in a 75GHz-spaced DWDM system with more than 3.5 dB of OSNR margin in the optical signal while remaining within the power consumption envelope of the QSFP-DD module’s power specification.

“This demonstration of high data rates over longer distances shows the potential of these game-changing products, and we expect to see increasing deployment of coherent pluggable modules with different use cases, from data center interconnect to metro and regional applications as well as 5G wireless backhaul,” said Tim Jenks, Chairman and CEO of NeoPhotonics. “Since the beginning of coherent transmission, NeoPhotonics has been at the forefront in meeting the volume needs of our customers, as is indicated by our recent announcement that we had shipped a cumulative total of more than two million ultra-narrow linewidth tunable lasers,” concluded Mr. Jenks.

https://www.neophotonics.com/press-releases/?newsId=12491

Monday, May 24, 2021

QSFP-DD Group releases Hardware and Common Mgt Interface Specs

The Quad Small Form Factor Pluggable Double Density (QSFP-DD) Multi Source Agreement (MSA) group released a hardware specification revision 6.0 updating QSFP-DD, introducing QSFP-DD800 and introducing QSFP112.

With the inclusion of support for 100 Gb/s electrical host interfaces, this 7th public release adds QSFP-DD800 and QSFP112 Mechanical and Board Definitions. It also adds QSFP112 electrical and management timing. Revision 6.0 includes updated power supply test methods and support for an increased module power rating to 25 W. The module power contact rating is increased from 1 A to 1.5 A. An appendix with normative connector performance data has also been added.


The group also announces the release of an updated Common Management Interface Specification (CMIS) revision 5.0 for QSFP-DD, QSFP-DD800 and QSFP112. The CMIS defines the host-to-module interactions needed to ensure that modules will initialize and operate consistently. This revision provides several extensions and a comprehensive technical and editorial consolidation. It is harmonized with timing parameters defined in QSFP-DD MSA HW Spec revision 5.1 previously published and in this revision 6.0. CMIS is broadly implemented across the industry, beyond just the QSFP/QSFP-DD family of module types. The feedback from many implementers has also been consolidated to improve and extend the specification.

“It is exciting to see how the 63 companies involved came together to harmonize these important QSFP/QSFP-DD form factors and software to future-proof data centers while maintaining backward compatibility,” said Scott Sommers, founding member, and MSA co-chair.

The MSA group also announces the release of a new thermal management whitepaper. High performance network environments need efficient cooling of pluggable optical modules. This is particularly true for the new high power 25 W modules for QSFP-DD800 systems, which must dissipate heat effectively to ensure operational performance. Careful thermal design of module, cage, heatsink, and the overall system for QSFP-DD modules is required for efficient heat dissipation. This new whitepaper explains techniques that can be used to achieve this goal in QSFP-DD/QSFP-DD800 module design and QSFP-DD/QSFP-DD800 system design. It includes both experimental and simulation studies to demonstrate the efficacy of these techniques.

“The performance and power demands for high-speed network solutions are constantly increasing,” said Mark Nowell, founding member, and MSA co-chair. “This whitepaper captures the design experience garnered over the recent years from many companies and was written to help design engineers understand how they can achieve the thermal characteristics their system requires, even when using new 25 W modules, thus ensuring the reliable operation of their products.”

http://www.qsfp-dd.com

Sunday, August 9, 2020

Precision OT debuts QSFP-DD 400G transceivers

Precision OT introduced its new line of QSFP-DD 400G optical transceivers supporting distances between 100m and 10km.

Precision OT is offering 4 different transceiver variants for this form factor to ensure that network operators' varying needs can be fully met. Precision's QSFP-DD transceivers support the continued growth of network traffic while being backwards compatible with existing QSFP optics.

"Optical transceivers, especially 400G-capable ones, are the key component in enabling more traffic to flow across today's networks," says Chris Page, CTO of Precision OT. "Single lambda 100G will be one of the most cost-effective ways for MSOs and data centers to deal with future bandwidth demands, because a single 100G line can reduce the costs of a typical 4x25G architecture by at least 40%. In this way, the use of four lines of 100G and PAM4 modulation can enable the 400G data rates our customers need to ensure they are ready for the future. For us, at Precision OT, it is about creating networking solutions that grow over time and accommodate increased demand cost-effectively, with both flexibility and agility."

http://www.precisionot.com

Wednesday, March 11, 2020

QSFP-DD800 MSA releases initial 800G transceiver spec

The Quad Small Form Factor Pluggable Double Density 800 (QSFP-DD800) Multi Source Agreement (MSA) group has released a new hardware specification for the QSFP-DD800 transceiver form factor.

The new QSFP-DD800 1.0 specification is intended to be incremental to the existing QSFP-DD 5.0 specification. As signal integrity and thermal performance remain imperative, the transceiver pads have been optimized to improve signal integrity for 100 Gbps performance per lane without affecting backwards compatibility. The new specification additionally defines a novel 2x1 connector/cage, with cabled upper ports as an option to address signal loss issues associated with tradition PCBs. Looking ahead, QSFP-DD800 promoters will continue to work on new connector/cage variants, including 2x1 SMT versions that operate at 100 Gbps per lane.

The MSA group was formed to advance the development of high-speed, double-density QSFP modules which support 800 Gbps connectivity and includes the following promoters: Broadcom, Cisco, II-VI, Intel, Juniper Networks, Marvell, Molex and Samtec.

“In the short time our group has collaborated, we are thrilled to introduce this first specification for the next generation of the QSFP family of modules,” said Scott Sommers, co-chair of the QSFP-DD800 MSA. “As signal integrity and thermal management remain challenges for the optical communications industry, our MSA group is confident that its solutions will meet performance needs.”

“With their superior system integration and design flexibility, QSFP modules continue to be the cornerstone in building next generation networks and network equipment, especially as port speeds increase to 800G,” said Mark Nowell, co-chair of the QSFP-DD800 MSA. “Furthermore, their ability to increase switch and routing bandwidth density without sacrificing backwards compatibility with QSFP-DD, QSFP56 and QSFP28 modules provide network operators tremendous commercial and operational advantages.”

http://www.qsfp-dd800.com

Thursday, September 19, 2019

QSFP-DD800 MSA gets underway

A new QSFP-DD800 Multi-Source Agreement (MSA) Group has been formed with the goal of advancing the development of high-speed, double-density quad small form factor pluggable (QSFP-DD800) modules to support 800 Gbps connectivity.

The MSA founder-promoters include Broadcom, Cisco, Finisar, Intel, Juniper Networks, Marvell, Molex and Samtec.

The new QSFP-DD800 interface expands on the QSFP-DD, a pluggable form factor with an eight-lane electrical interface widely adopted by the latest Ethernet switches. This MSA will enable QSFP-DD800’s eight electrical lanes to operate at 100 Gbps each, by providing technical solutions for 800 Gbps module and connector systems. It will also define a module, connector, stacked connector and a hybrid connector that is a BiPass/Flyover variant which can eliminate the signal losses on a traditional PCB. The primary objective of the MSA Group is to define the specifications and promote industry adoption of the QSFP-DD800. The new QSFP-DD800 specification is intended to be backward compatible with QSFP-DD, QSFP28 and QSFP+ modules and cables in order to address the upcoming industry demands of 25.6 Tb/s scale systems supporting dense 100 GbE or dense 400 GbE interfaces.

“Through continued strategic collaborations with our MSA Promoters, we are developing the physical specifications that will enable the interoperability of optical transceiver modules, connectors, cages and DAC cables from multiple vendors to assure a robust ecosystem,” said Scott Sommers, founding member and MSA co-chair. “We are thrilled to collaborate together as a group and further develop and provide next-generation designs that evolve with the changing technology landscape.’’

“Leveraging the technical innovations from QSFP-DD, the time is right to collaborate with our MSA partners to lay the foundations for the next generation systems and modules,” said Mark Nowell, founding member and MSA co-chair. “The QSFP-DD form factor continues to be the cornerstone for the next step in pluggable module performance and density, while extending the industry’s investment, experience, cost structure and backward compatibility from prior generations.”

http://www.qsfp-dd800.com

Thursday, July 18, 2019

TE intros QSFP-DD connectors, cages and cable assemblies for 400G

TE Connectivity (TE) introduced its new Quad Small Form Factor Pluggable Double Density (QSFP-DD) connectors, cages and cable assemblies, which address next-generation data center needs by increasing density through an existing QSFP form factor to reach speeds up to 400 Gbps. This 8 lane solution is designed for both 28G NRZ and 56G PAM-4 protocols, with a roadmap to 112G PAM-4 for future system upgrades.

“As the world marches toward next generation connectivity in data center equipment, designers need new connector and cable assembly solutions to support this change,” said Zach Galbraith, product manager at TE Connectivity.  “We are excited to be one of the premier suppliers bringing QSFP-DD products to our customers, enabling 400 Gbps data rates through a single port. These products can provide much-needed flexibility to the industry’s end users, platform designers and system integrators.”

TE notes that its -DD products are backward-compatible. The new QSFP-DD products leverage proprietary zipper fin heatsink technology allowing them to work cost-effectively in 15-18W applications.

TE offers a broad QSFP-DD portfolio which includes 1x1 through 1x6 cages and surface mount (SMT) connectors on a 0.8mm pitch, along with various lengths and wire sizes of straight and breakout passive copper cable assemblies. Customer specific designs with different lightpipes, heatsinks and cable assemblies are also available, supported by TE signal integrity experts.

https://www.te.com/usa-en/products/connectors/pluggable-connectors-cages/qsfp-dd.html?tab=pgp-story

Video: The Road to On-Board Optics w Nathan Tracy of TE Connectivity



One minute video: Nathan Tracy at TE Connectivity discusses how COBO utilizes TE's high-speed connector and how the two companies form an industry partnership to enable new aggregate bandwidth rates for next-generation optical data centers.

https://youtu.be/_QNJqZY_RGg

Thursday, July 11, 2019

QSFP-DD MSA Group updates two specs

The Quad Small Form Factor Pluggable Double Density (QSFP-DD) Multi Source Agreement (MSA) released two updated specifications: Common Management Interface 4.0 and Hardware Specification 5.0.

QSFP-DD is an 8-lane data center module form factor. Systems designed for QSFP-DD modules can be backward compatible with existing QSFP form factors and provide maximum flexibility for end users, network platform designers, and integrators.

The updated Common Management Interface Specification (CMIS) revision 4.0 can be used as a common interface by other 2, 4, 8 and 16 lane form factors, in addition to QSFP-DD. Other notable features include firmware upgrade, diagnostic capabilities, improved State Machine support as well as support for WDM / Coherent modules.

The updated hardware specification revision 5.0 for QSFP-DD. This update supports up to 20 watts with improved thermal management. It includes new optical connectors; SN and MDC, a label area specification, improved latching definition and enhanced Pulse Per Second (ePPS) pin.

“Through strategic collaborations with our MSA companies, we continue to test the interoperability of multiple vendors’ modules, connectors, cages and DAC cables to assure a robust ecosystem,” said Scott Sommers, founding member and MSA co-chair. “We remain committed to developing and providing next-generation designs that evolve with the changing technology landscape.’’


“As the industry continues to converge on QSFP-DD, we believe the economies of scale will manifest and allow 400GbE to reach its full potential,” said Mark Nowell, founding member and MSA co-chair. “We are excited to share new updates and grow the previous thermal and high-speed signal integrity validation previously shared by the MSA.”

Contributors include Acacia, ACON, Alibaba, Amphenol, Applied Optoelectronics, APRESIA Systems, Celestica, Ciena, ColorChip, Credo, Dell EMC, Delta Products, Dust Photonics, Eoptolink, Fourte, Fujitsu Optical Components, Genesis, H3C, Hisense Broadband, Hitachi Metals, Hewlett Packard Enterprise, InnoLight, Innovium, Inphi, JPC, Kaiam, Keysight Technologies , LEONI, Lorom, Luxshare-ICT, MACOM, Marvell, MaxLinear, MultiLane, NeoPhotonics, Nokia, Panduit, PHY-SI, Ranovus, Samtec, SENKO, Semtech, Sicoya, Siemon, Skorpios Technologies, Source Photonics, Spectra7 Microsystems, Spirent, Sumitomo Electric, US Conec, Xilinx and Yamaichi Electronics.

The QSFP-DD MSA specifications are available for free download at the QSFP-DD MSA website

http://www.qsfp-dd.com

Thursday, September 6, 2018

Anritsu adds 53 Gbaud upgrade for PAM4 optical signal analysis

Anritsu has released new firmware downloads for the BERTWave MP2110A Sampling Oscilloscope that boosts its PAM4 analysis function from 26 Gbaud to 53 Gbaud for the production and inspection of optical modules.

Anritsu notes that current optical modules such as CFP8s use 26-Gbaud PAM4 optical signals, while future mass-produced QSFP-DD and OSFP modules will use 53-Gbaud PAM4 optical signals. Its solution can be used to support the development and production-line inspection of next-generation QSFP-DD optical transceivers expected to be deployed in data centers.

The BERTWave MP2110A is an all-in-one measuring instrument with built-in multi-channel Bit Error Rate Tester (BERT) and Sampling Oscilloscope, supporting bit error rate (BER) measurements, Eye Mask tests, Eye pattern analyses, high sampling speed of 250 kSample/s and low-noise (3.4 μW) high-sensitivity O/E interface. The BERT and Sampling Oscilloscope are required instruments for evaluating optical modules used by optical communications systems.

As well as NRZ technology, the MP2110A also supports PAM4 signal measurements including TDECQ, which enable all-in-one quality evaluations of optical modules at speeds from 25 to 400 G. In addition, the MP2110A, thanks to its high-speed measurement and PAM4 analysis, will play a key role in improving optical module production-line productivity. Moreover, adding 53 Gbaud support for quality evaluation of next-generation optical modules helps cut capital equipment renewal costs.


Thursday, August 30, 2018

QSFP-DD MSA Group completes mechanical plugfest

The Quad Small Form Factor Pluggable Double Density (QSFP-DD) Multi Source Agreement (MSA) completed a mechanical plugfest to validate the compatibility and interoperation between member’s designs.

The MSA said the event confirmed that the maturity of design experience resulted in a highly successful outcome. A key value proposition of QSFP-DD form factor is the backward compatibility with the widely adopted QSFP28.

The areas of focus for this event included testing the electrical, latching and mechanical designs all of which address the industry need for a high-density, high-speed networking solution.

In total, 15 companies participated in the private Plug Fest, which was hosted by Cisco at their headquarters in San Jose, California.

http://www.qsfp-dd.com/

New QSFP-DD MSA Targets 400G


The Quad Small Form Factor Pluggable Double Density (QSFP-DD) Multi Source Agreement (MSA) group has released a specification for the new QSFP-DD form factor, which is a next generation high-density, high-speed pluggable module with a QSFP28 compatible double-density interface. QSFP-DD pluggable modules can quadruple the bandwidth of networking equipment while remaining backwards compatible with existing QSFP form factors used across Ethernet, Fibre...

Thursday, September 21, 2017

Eoptolink samples 200G 2×CWDM4 QSFP-DD

Eoptolink, a supplier of optical components based in Chengdu, China, has begun sampling a 200G CWDM4 QSFP-DD optical module.

QSFP-DD doubles the density of QSFP28.

The new device is based on 8x25G NRZ DML technology and fully complies with QSFP-DD and CWDM4 MSA. The company will offer 2km and 10km versions.

Eoptolink is also developing 400G transceivers.
