Sunday, September 23, 2018

ECOC 2018: Progress with the 100G Lambda MSA

The 100G Lambda Multisource Agreement (MSA) Group, which was formed in October 2017, announced the release D2.0 of three specifications based on 100 Gbps per wavelength PAM4 optical technology.

These updated 100 GbE interface specifications are designated as 100G-FR and 100G-LR for duplex single mode links over 2 km and 10 km respectively.

The MSA has also updated the 400G-FR4 specification for 400 GbE duplex single mode fiber links relying on multiplexing 4 wavelengths of 100 Gb/s PAM4 modulated optical signals. In addition, the MSA is also working on a 400G-LR4 specification for a 10 km reach at 400 GbE.

Plugfest


In addition, members of the 100G Lambda MSA Group announce recently conducted a private interoperability private plugfest hosted by MultiLane. Twelve companies participated.

The areas of focus for this event included testing optical interoperability for 100 GbE and 400 GbE modules and modules that support 4x 100 GbE breakout.

“The rapid convergence of stakeholders and technical agreement highlights the strong industry effort and the demand to bring this technology to market as soon as possible,” said Mark Nowell, MSA co-chair.

“The successful testing between so many members involved in the plugfest shows the rapid maturity of the various product and technology developments across the ecosystem,” said Jeffery Maki, MSA co-chair.

At ECOC, the 100G Lambda MSA Group is hosting module interoperation demonstrations in the 100G Lambda MSA booth (Booth #123)/

The 100G Lambda MSA Group member companies are: Alibaba, Applied OptoElectronics, Arista, Broadcom, Ciena, Cisco, Color Chip, Credo, Delta, Finisar, Foxconn Interconnect Technologies, Fujitsu Optical Components, HiSense, Huawei, IDT, Inphi, Intel, Juniper Networks, Kaiam, Keysight Technologies, Lumentum, Luxtera, Macom, Maxlinear, Mellanox, Microsoft, Mitsubishi Electric, MultiLane, Molex, Neophotonics, Nokia, Oclaro, Rockley Photonics, Semtech, Sicoya, Source Photonics, Sumitomo Electric, TE Connectivity and Tektronix.

www.100glambda.com


ECOC 2018: Source Photonics demos 50G and 400G PAM4 transceivers

Source Photonics will be participating in the Ethernet Alliance interoperability demonstration showcasing live traffic-utilizing 50G and 400G PAM4-based optical transceivers in OEM equipment at ECOC 2018, September 24-26 in Rome, Italy.

The live demonstration at the Ethernet Alliance Booth #618 will consist of multiple 400G and 50G links among participating network and test equipment manufacturers.

Source Photonics will contribute its 400GBASE-LR8 transceivers in QSFP-DD and CFP8 form factor as well as its 50GBASE-LR QSFP28 modules. Live traffic will be passed among the equipment of Ethernet Alliance member companies including Exfo, Huawei, Ixia, Spirent and Viavi.

Ed Ulrichs, Director PLM, commented: “Source Photonics offers advance solutions to support the migration to the next higher networking speed. The demonstration of our latest 50G and 400G optical transceivers attests the readiness of this technology for wide-scale deployment by connecting them to the networking equipment of various OEMs and proving interoperability.”

Source Photonics also said that it is now accepting sample orders for the high speed 400G QSFP-DD. The company is scheduled to go into production in January 2019. This small form factor module enables the migration to the next higher data rate in a wide field of applications such as datacenter connectivity, optical transport networks and metro networks.

The 50G QSFP28 will be in full production late this year and will support the expansion to converge networks in metro access and 5G applications.

Source Photonics -- booth #416
Ethernet Alliance -- booth #618

ECOC 2018: Keysight and Ixia demo 400GE and 110 GHz signal analysis

At ECOC 2018, Keysight Technologies is demonstrating its latest high-speed, test solutions in a private room (building SC3, room J), including coherent signal analysis solutions featuring the new Infiniium UXR-Series Real-Time Oscilloscopes and the new N4391B Optical Modulation Analyzer with up to 110 GHz Bandwidth, as well as the M8194A 120 GSa/s arbitrary waveform generator (AWG). The room will include demonstrations of new optical and electrical 400GE / PAM4 compliance test solutions, as well as 1.2 Terabit and 400ZR test equipment for coherent optical applications.

Ixia, a Keysight business, is also demonstrating its 400 Gigabit Ethernet (GE) test solutions in cooperation with other organizations. With the Ethernet Alliance (Stand 618), Ixia will participate in the first multivendor demonstration of interoperability in the 400GE ecosystem with a 400GE switch over OSFP optical transceivers which leveraged all 8 ports in the AresONE OSFP 8x400GE test system to deliver 3.2 Tbps of live Ethernet traffic. The demo also uses passive copper Direct Attached Cable (DAC) assemblies from Amphenol and TE Connectivity Ltd.

Keysight and Ixia solutions are also present at:

  • Fujitsu Optical Components (FOC) (Stand 703) is showing Keysight's N1092C DCA-M sampling scope with N1078A optical/electrical clock recovery unit and 86100D DCA-X mainframe with 86108B precision waveform analyzer for the development of their 400G OSFP/QSFPDD transceivers.
  • HUBER+SUHNER Cube Optics AG (Stand 410) will present a live demo at its booth of its latest ultra-compact integrated multi-lambda 200 Gbps PAM4 Receiver Optical Sub-Assembly (ROSA), compatible with the 200G and 400GBase-FR8 standard using Keysight’s N1092E DCA-M sampling oscilloscope for analysis.
  • Ciena (private room) is using Keysight’s M8290A optical modulation analyzer (OMA) to demonstrate its Wavelogic Ai coherent applications.
  • Finisar (Stand 400) is demoing their leading optical transceiver modules operating in the Ixia’s 2nd generation 400GE, AresONE test system. The demonstration consists of AresONE ports transmitting and receiving up to 3.2 Tbps of live Ethernet test traffic with Forward Error Correction (FEC).
  • Source Photonics (Stand 416) is demonstrating the maturity of the 400GE ecosystem using their 400G QSFP-DD LR8 transceiver and traffic from Ixia’s field-proven K400 QSFP-DD test system.
  • Mellanox Technologies (Stand 432) is using Ixia's AresONE 8x400GE QSFP-DD test system to demonstrate 200Gb/s live traffic using 200GBASE-SR4 multimode fiber transceivers and 400Gb/s QSFP-DD passive copper DAC assemblies.
  • Molex (Stand 606) will demonstrate line rate 400G Ethernet traffic with Ixia’s K400 over Molex’s new 3m QSFP-DD DAC. Real-time analysis on K400 will showcase test results of pre-FEC (forward error correction) per lane BER (bit error rate) better than IEEE specifications.

ECOC 2018: NeoPhotonics shows 400G EML and silicon photonics

At ECOC 2018 this week in Rome, NeoPhotonics is showing its suite of lasers and analog ICs for uncooled, non-hermetic single laser 100G and 4 laser 400G links within data centers.    The product suite includes Electro-Absorptively Modulated Lasers (EML) for 2 km PAM4 based links and high power CW laser sources for 0.5 and 2 km Silicon Photonics-based links, along with the photodetectors, drivers and trans-impedance amplifiers required.

NeoPhotonics anticipates a technology shift to single-laser (lambda) 100Gbps and 4-laser (lambda) 400Gbps using 4 level pulse amplitude modulation (PAM4) driven by demand for higher port density and lower cost per bit for optical connections inside the data center.

The 100G/400G Component Suite from NeoPhotonics includes:

  • 53GBaud Uncooled CWDM4 EML, which includes the option for integration with NeoPhotonics’ open drain driver. With an uncooled operating temperature range from 20 to 70C and the capability to operate reliably in “open-air” transceiver designs, thus eliminating hermetic enclosures, this EML is a preferred transmitter solution for PAM4 based FR4 2 km data center applications. Versions are also available at 1310 nm for DR1 and DR4 500 meter applications.
  • 53GBaud Open Drain Driver (ODD) for linear operation of EML lasers. With a typical 90mW of power consumption per channel and small size, this high speed driver can be co-packaged with the EML reducing power and increasing linearity and is well suited for use in small form factor pluggable modules.
  • 53GBaud PIN photodetectors. The side illumination structure of the PIN PD enables a simple coplanar assembly with a mux/demux chip and TIA and is well suited for compact modules.
  • 53GBaud Transimpedance Amplifier (TIA). With low noise and a typical power consumption of 60mA over a 3.3V rail, this TIA is well suited for receiver signal amplification for up to 10km transmission.

In addition, transceiver developers have also begun deployment of silicon photonics based transceivers for industry standard MSAs such as CWDM4, CLR4 and PSM-4, which has led to the need for custom, high power and non-hermetic laser sources to drive these transceivers. To support this emerging Silicon Photonics eco-system, NeoPhotonics has developed and qualified a line of high power, uncooled lasers and laser arrays for several industry leading Silicon Photonics transceiver manufacturers, as well as offering single and quad drivers for Silicon Photonics modulators:

  • High Power 40mW and 70mW non-Hermetic CW Laser Sources for Silicon Photonics based CWDM4 FR4 and 1310nm DR1 and DR4 Applications. These efficient, high power DFB lasers can operate up to 75 deg. C and have completed the non-hermetic testing compliant with the Telcordia GR-468-CORE, making them well suited for use in non-hermetic Silicon Photonics based small form factor pluggable modules.
  • 53GBaud Quad MZM drivers for Silicon Photonics modulators. This quad driver has a high 3.5Vppd output per channel and a typical 2.2W low power consumption for all four channels designed for small form factor pluggable modules.  This component is also available in single driver configurations for DR1 applications.

“Our complete suite of 53GBaud Linear Optical Components provides all needed optical components for single laser 100Gbps transmitters and receivers, scalable to 400Gbps transceivers with CWDM4 wavelengths,” said Tim Jenks, Chairman and CEO of NeoPhotonics.  “Furthermore, our uncooled, high power CW DFB lasers and laser arrays are critical elements for any 100G, 200G or 400G Silicon Photonics based transceiver.  We are pleased to offer the lasers and critical analog electrical components for both next generation data center transceiver approaches,” continued Mr. Jenks.

www.neophotonics.com

ECOC 2018: NeoPhotonics cites progress with 64 GBaud for 600G

At ECOC 2018L NeoPhotonics is reporting that its suite of 64 GBaud optical components for coherent systems are currently being used by multiple major customers to develop systems with 600G per wavelength transport capacity.   64 GBaud components double the symbol rate over standard 100G (32 GBaud) coherent systems.

NeoPhotonics' suite consists of three components:

  • 64 GBaud CDM:  NeoPhotonics 64 GBaud, polarization multiplexed, quadrature coherent driver modulator (CDM) is shipping in limited availability and features a co-packaged InP modulator with a linear, high bandwidth, differential driver in a compact package designed to be compliant with the anticipated OIF Implementation Agreement.
  • 64 GBaud Micro-ICR:  NeoPhotonics Class 40 High Bandwidth Micro-Intradyne Coherent Receiver (Micro-ICR) is in volume production and is designed for 64 GBaud symbol rates, doubling the bandwidth of standard 100G ICRs. The compact package is designed to be compliant with the OIF Implementation Agreement OIF-DPC-MRX-02.0.
  • Low Profile Micro-TL:  NeoPhotonics ultra-narrow linewidth external cavity tunable laser features very low phase noise and power consumption and has been proven in volume production. It is now configured in a smaller, lower profile package that is compliant with the OIF Implementation Agreement OIF-MicroITLA-01.

These components work together to enable customers to implement single wavelength 600G or dual wavelength 1.2T data transmission over data center interconnect (DCI) distances of 80 km.

“We are working closely with customers to provide a matched suite of high speed optical components for 600G per wavelength to enhance system performance and reduce time to market,” said Tim Jenks, Chairman and CEO of NeoPhotonics.  “With our next generation highly integrated COSA, operating at 64 Gbaud and beyond, and our Nano-Tunable Laser, we are working to enable highly compact pluggable 400G modules,” continued Mr. Jenks.

The company says three OEM customers have elected to use all three of these components in their development, while additional customers have elected to use a subset of the NeoPhotonics 64 GBaud coherent component suite.  The components also support 400G over metro distances of 400-600 km using 64 GBaud and 16 QAM or 200G over long-haul distances of greater than 1000 km using 64 GBaud and QPSK.

In addition, at 16:10 pm on Tuesday, September 25th Dr. Winston Way, NeoPhotonics’ CTO Systems, will present a paper entitled “Next-Generation Coherent Pluggable Transceivers in a CDC ROADM Based Optical Network” at the ECOC 2018 Exhibition Market Focus session entitled: “Optical Network Agility/Software Defined Networks.”

ECOC 2018: 5G requires fiber network infrastructure - Source Photonics

There may be a vast number of opportunities for mobile fronthaul and backhaul on the horizon but improvements in protocols, standards and technology will also need to be made, according to Supriyo Dey, Senior Director Product Line Management at Source Photonics, speaking on the opening day of the ECOC 2018 Exhibition, taking place in Rome, Italy.

Dey commented: “While an exciting era of unprecedented opportunity is almost here in the shape of 5G, it comes with a set of challenges for the whole industry. The advent of this technology is undeniably huge, but there’s a real challenge for those who are hungry to develop its capabilities to match their expectations in terms of performance. Applications such as 3D video, augmented reality, UHD screens, self-driving cars and smart cities to name a few will need to be supported by mobile front and backhaul.

“With these advances in capabilities come new requirements -, up to 10Gb/s data rate to support high quality video, ultra-reliable and low latency communication for autonomous vehicles and massive node communications for them Internet of things.

“The current 4G optical fronthaul and backhaul architecture will not be adequate to support these new applications. While several optical fronthaul and backhaul solutions have been proposed, we have yet to see a clear winner.”

Dey’s observations were delivered at the ECOC18 Exhibition’s Market Focus, as part of an agenda that tackled topics ranging from FTTX evolution and next-generation data centers to optics as an enabler for 5G.

Source Photonics is also showcasing some of its latest products at the exhibition in the form of live demos.

This includes a demonstration with equipment testing experts Ixia, of its 400G QSFP-DD LR8 transceiver. In addition, the company will also demonstrate its 25G SFP28 LR Lite which supports CPRI wireless and 25GBASE-LR applications.

www.sourcephotonics.com

ECOC 2018: IDT debuts100G Single Lambda EML driver and TIA for 200G/400G

At ECOC 2018, Integrated Device Technology (IDT) is introducing its latest single lambda EML driver and TIA for 200G/400G datacenter applications.

IDT said its 400GbE based on 100G single lambda designs will establish an ecosystem to lower the cost per bit, a key enabler for scalable Switch-to-Switch and Switch-to-Server Optical Links, supported with small form factor modules, such as 200G/400G QSFP-DD, OSFP and 400G OBO. The Electro-Absorption Modulated Laser (EML) and Trans-Impedance Amplifier (TIA) are key analog IC components, and the features of IDT's chip set of high bandwidth, high sensitivity and low power consumption are promising to support those modules.

The IDT 100G single lambda EML Driver is available as a die (HXT45100) and as a packaged driver (HXT45x01) with 1 or 4 channels. The driver family features broad bandwidth, high linearity and low power consumption for the QSFP-DD module form factor. The SMT-type packaged drivers integrate built-in Bias-T, internal high-frequency chokes and input DC blocks, and offers 2Vpp output voltage swing while consuming less than 300mW per channel power.  The bandwidth is over 40GHz with excellent phase flatness and channel isolation.

The 100G single lambda TIA, offered as 1 channel and 4 channel dies (HXR45x00),  provides under 5kohm transimpedance gain, 500mVpp maximum differential output voltage, excellent flat frequency response and low group delay with 3dB bandwidth higher than 36GHz, is very suitable for 100G single lambda applications, with a power dissipation as low as 168mW per channel. The HXR45x00 is configurable by I2C, for 28G applications, with a flat frequency response and 3dB bandwidth of 25GHz and reduced power dissipation down to 135mWper channel.

"We are very excited of the initial results of our single channel and four channel 112G/ch TIA," said Andrea Betti-Berutto, IDT Fellow. "This new generation of TIAs will well satisfy the high performance challenges required for 100G single lambda applications and simultaneously consume very little power and deliver a high sensitivity solution for lower rate applications, such as 28Gbaud-based small form factor modules."

Molex acquires Nistica for wavelength selective switching (WSS)

Molex has acquired Nistica, a manufacturer of wavelength selective switching (WSS) products. Financial terms were not disclosed.

Nistica, which was founded in 2005 and is based in Bridgewater, New Jersey, is a supplier of agile optical modules that simplify, automate and make affordable the delivery of high bandwidth applications for the global telecommunication markets. The company specializes in WSS, a signal routing engine for metro/long-haul telecom networks.

Molex said Nistica's wavelength management solutions will enhance its portfolio of solutions for metro and long-haul networks. Nistica’s business will be integrated into the Molex Optical Solutions Group, a global provider of optical solutions, including a wide range of optical connectivity, optoelectronics, and optical transport products.

"With the build-out of 5G wireless networks and the growth in data center traffic, our customers are looking for novel optical solutions at the edge and in the core of optical networks," added Ashish Vengsarkar, CEO of Nistica. "The acquisition by Molex enables us to scale in capacity and bring a comprehensive portfolio of next-generation products to the market.”

“The addition of the highly innovative Nistica team and technology portfolio to our business enables us to continue our mission of helping customers drive innovation in areas where optical technology provides them with a competitive advantage,” said Doug Busch, vice president and general manager, Molex Optical Solutions business unit. “Integrating high-port count WSS capability into our optical transport portfolio will allow us to expand our offering to customers driving the dynamic growth of communications networks.”

Comcast's acquisition of Sky brings 23m customers in 7 countries

Comcast NBCUniversal prevailed over 21st Century Fox and Walt Disney in an auction to acquire Sky, the leading entertainment and communications company in Europe.  The offer of £17.28 per Sky shareimplies a value of $40.0 billion (£30.6 billion) for the fully diluted share capital of Sky.

Sky serves 23 million customers in seven countries – U.K., Ireland, Germany, Austria, Italy, Spain, and Switzerland. Sky has TV ownership rights to English Premier League football for three years starting in 2019. It also holds exclusive partnerships with HBO and Showtime. Sky News is a top European cable news network, and there are additional Sky channels for sports, entertainment, and the arts. In addition, Sky Broadband is a leading (#2) residential broadband provider in the U.K./Ireland, and a new Sky Mobile MVNO was recently launched in Europe. Sky's 2017 revenue was $18.5 billion.

Comcast Chairman and CEO Brian L. Roberts said: “This is a great day for Comcast. Sky is a wonderful company with a great platform, tremendous brand, and accomplished management team. This acquisition will allow us to quickly, efficiently and meaningfully increase our customer base and expand internationally. We couldn’t be more excited by the opportunities in front of us. We now encourage Sky shareholders to accept our offer, which we look forward to completing before the end of October 2018.”
