Monday, August 28, 2017

Champion ONE ships 10km 25G SFP28 LR transceiver

Champion ONE announced commercial availability of its new portfolio of 25G SFP28 hot-pluggable transceivers. The company said its new transceivers are universally compatible across various OEM switch and router platforms .

The new low-power transceivers are based on the SFP+ MSA form factor, and support 25G Ethernet and 24.3G CPRI. They come in two versions: the SR (rated 70m on OM3 multimode fiber or 100m on OM4 multimode fiber) and LR (rated 10km on single mode fiber). The LR is available in both commercial temperature (0 to 70° C) and hardened (-40 to 85° C) versions to support deployment in uncontrolled environments. The power consumption is only 1.0W (SR) and 1.5W (LR) for these transceivers

”We continue to innovate and support our customers’ need for expanded bandwidth,” said Champion ONE CEO John Jutila. “By leading the industry with the release of our new portfolio of 25G transceivers, our carrier customers can use these products for expanded 5G LTE wireless fronthaul applications or 4x25G breakout configurations for their 100G Ethernet links and our enterprise customers can deploy them as a low cost migration to higher data rates.”

http://www.championone.com

Monday, March 27, 2017

Luxtera Begins Volume Shipments of 2 x 100G PSM4

Luxtera, a developer of silicon photonics technology, announced shipping in volume of what it claims it the first 2 x 100 Gbit/s PSM4 (parallel single mode fibre 4-lane) embedded optical transceiver, designed for cloud data centre, enterprise and telecom networking applications.

The company noted that the compact LUX62608 OptoPHY module was developed employing its patented and proven silicon photonics integration platform and is designed to deliver high density with long reach optics at significantly lower cost than using two 100 Gbit/s front panel pluggable QSFP modules.

Luxtera's OptoPHY 2 x 100G-PSM4 solution includes eight independently operating transmitter and receiver channels, integrating high-speed phase modulators, photodetectors, waveguides, grating couplers, high-speed electrical retimers and control circuitry and is powered by a single integrated laser. The components are packaged in a silicon photonics chipset, with no additional external elements required.

Key features of the product include: 200 Gbit/s aggregate bandwidth optical transceiver; compliance with 2 x 100G PSM4; 8 x 26 Gbit/s independently operating channels with full-duplex operation; multi-rate 1-25.78 Gbit/s per channel performance; extended reach of up to 2 km; and typical power consumption of less than 5 W.

Luxtera stated that the OptoPHY 2 x 100G-PSM4 optical transceiver has been selected by Ericsson as the optical interconnect for its Hyperscale Datacenter System, HDS 8000, a cloud computing system with a disaggregated architecture. OptoPHY serves as the optical interconnect for the HDS 8000's compute, networking and storage sleds and helps to eliminate tradeoffs between reach and cost performance.

http://www.luxtera.com

Inphi unveils 64 Gbaud linear TIA/VGA amplifier

Inphi announced production availability of its IN6450TA 64 Gbaud dual channel linear TIA/VGA amplifier, and that its 32 Gbit/s quad linear TIA with analogue and digital SPI interfaces and second-generation single chip quad channel linear driver in bare die form will be combined as a chipset to address the requirements of 100/200 Gbit/s coherent systems for metro and long haul applications.

64 Gbaud linear TIA/VGA amplifier

Inphi has announced production availability of its IN6450TA device, claimed as the first 64 Gbaud dual channel linear TIA/VGA amplifier, offering support for data rates of 400 to 600 Gbit/s per wavelength and targeting long haul, metro and data centre interconnect (DCI) applications.

The company noted that with growing demand for bandwidth, service providers and data centre operators require more efficient technologies, such as flexible coherent DWDM transmission capable of changing transmission capacity and reach on demand. This capability is enabled through the use of components capable of supporting multiple modulation formats and baud rates; the IN6450TA is designed to work with modulation formats supporting data rates of up to 600 Gbit/s on a single wavelength.

Inphi stated that it worked with NeoPhotonics on the design of the IN6450TA and its incorporation into NeoPhotonics' 64 Gbaud micro-ICR targeting applications in high-density line cards and pluggable transceivers.

Chipset for 100/200 Gbit/s coherent systems

The IN3254TA and IN3226DZ devices are designed to be integrated to enable higher density, lower cost solutions for emerging coherent optical sub-assembly (COSA) components. COSA implementations are designed to enable delivery of the newly proposed CFP2-DCO form factor, as well as provide the more compact, lower cost ACO modules with higher port-count line cards for 100/200 Gbit/s coherent transmission applications.

Inphi noted that for 100 Gbit/s, a major part of the growth is attributed to the CFP2 coherent modules expanding the addressable market for pluggable transceivers. The company's new transceivers are intended to enable the next generation of 100 and 200 Gbit/s networking infrastructure for metro and inter-data centre markets, where smaller size, lower cost and pluggable modules are the key requirements.

https://www.inphi.com

ColorChip Demonstrates 200G QSFP56 PAM4

ColorChip, a developer of integrated optical components and sub-systems for high speed networking, announced technology demonstrations at OFC 2017 including uncooled CWDM4 DML devices driving both PAM4 and NRZ modulation and packaged in QSFPx form factors; the company also announced volume production of its 100 Gbit/s CWDM4 QSFP28 product.

200 Gbit/s QSFP56 PAM4 with CWDM4 DML

ColorChip presented several demonstrations utilising uncooled CWDM4 DML technology, including the exhibition of 200 Gbit/s PAM4 featuring TOSA and ROSA based on the company's patented SystemOnGlass platform and leveraging field-proven 40/100 Gbit/s deployments, with extension beyond 400 Gbit/s.

ColorChip noted that the link demonstrates the building blocks that can enable a compact, low power 200 Gbit/s PAM4 transceiver using the CWDM4 grid, packaged in a compact QSFP56 form factor and with a standard duplex LC optical interface.

2 x 100 Gbit/s CWDM4 in QSFP-DD

ColorChip is also showing a 2 x 100 Gbit/s 'two in a box' solution based on its SystemOnGlass technology implementing an 8-channel TOSA and ROSA to create a dual CWDM4 transceiver in QSFP-DD or OSFP form factor. At OFC the 8 channel optical engines, which include dual embedded CWDM4 multiplexers, enable a 2 x 100 Gbit/s CWDM4 QSFP-DD transceiver with 8 x 25 Gbit/s NRZ electrical interface and dual duplex-LC optical connectors.

Mass production of 100 Gbit/s CWDM4 QSFP28

ColorChip also announced volume production of its 100 Gbit/s CWDM4 OCP-accepted transceiver, which offers an optical interconnect with low power consumption of 2.6 W and delivering reach of 500 metres, which can be extended to 10 km. Provided in the 4WDM-10 MSA specification, the transceiver targets inter-data centre and campus connectivity applications.

Manufacturing expansion

In order to meet growing demand for data centre networking, ColorChip stated that it has completed $60 million in funding over the past 18 months to support a significant expansion of its industrialised-optics TOSA/ROSA assembly lines in Israel. The company has also partnered with contract manufacturer Fabrinet for the optical module integration and final testing.

ColorChip stated that over the past 6 months, it has doubled production floor space to 20,000 sq feet and increased head count to more than 300 employees.

http://www.colorchip.com

Sunday, September 18, 2016

NeoPhotonics Announces 64 Gbaud Micro-Intradyne Coherent Receiver

NeoPhotonics has begun sampling a Class 40 High Bandwidth Micro-Intradyne Coherent Receiver (HB Micro-ICR) capable of supporting 64 Gbaud symbol rates, which is double the bandwidth of standard 32 Gbaud ICRs.

The company said its new HB Micro-ICR supports higher order modulation up to 64 QAM, which when coupled with NeoPhotonics ultra-narrow linewidth, external cavity Micro-ITLA laser, can achieve 600 Gbps over Datacenter Interconnect distances of 80 km.

Similarly, using Dual Polarization QPSK modulation the HB Micro-ICR extends the reach to 2000 km at 200Gbps, double the data rate of standard coherent transmission.  By using NeoPhotonics advanced coherent components, system designers can increase the bandwidth by up to a factor of six and dynamically change the reach and modulation format while keeping the number of components unchanged, enabling software defined networks (SDN) and greatly reducing the cost per bit.

“Our new HB Micro-ICR enables coherent system designers to greatly reduce the cost per bit by getting much higher data-rates out of the same number of optical components while at the same time flexibly changing the reach and data rate under software control in SDN,” said Tim Jenks, Chairman and CEO of NeoPhotonics.  “This exciting new product is made possible by our Advanced Hybrid Photonic Integration technology and, along with our line of Multi-Cast Switches, helps enable our customers to achieve their vision of a completely flexible high speed network that can dynamically adjust to changing needs,” continued Mr. Jenks.

http://www.neophotonics.com

Thursday, August 11, 2016

Acacia Posts Revenue of $116.2M, up 101% YoY

In its first financial report as a public company, Acacia Communications posted Q2 revenue of $116.2 million, up 101% year-over-year. GAAP gross margin came in at 46.4% of revenue and GAAP net income was $17.6 million.

“Our record second quarter results exceeded our expectations across the board and reflect the success of our disruptive technology in transforming cloud, content and communications networks.  These results are a testament to our strategy and demonstrate our leadership position in the high-growth 100G plus optical networking market,” said Raj Shanmugaraj, President and CEO of Acacia Communications, “We continue to see strong global demand for our products, driven by metro and inter-data center network infrastructure buildouts.”

Acacia, which was founded in 2009, develops  high-speed coherent optical interconnect products, including a series of low-power coherent DSP ASICs and silicon PICs.  The company has integrated into families of optical interconnect modules with transmission speeds ranging from 40 to 400 Gbps for use in long-haul, metro and inter-data center markets. Acacia’s coherent DSP ASICs and silicon PICs are manufactured using CMOS and CMOS-compatible processes. The company completed its IPO during Q2.

Thursday, April 21, 2016

Video: Source Photonics Demos PAM4 - 2x50G QSFP28

Pulse Amplitude Modulation encodes information in the amplitude of a series of signal pulses.

In this video, Dr. Manish Mehta, EVP of Product Line Management at Source Photonics, introduces the fundamentals of PAM4 encoding, which is expected to play a major role in enabling lower cost, 100Gbps data center connections.

Source Photonics conducted a live demonstration of PAM4 2x50Gbps QSFP28 transceivers at #OFC2016. These will add to the company's portfolio of small form factor 100G optical transceivers.

The PAM4 demonstration comes on the heels of Source Photonics’ industry leading release of the 100G QSFP28 LR4 platform of products. Source Photonics announced first in industry sampling of the LR4 and LR4 Lite in March 2014 and mass production in March 2015. In January 2016, Source Photonics announced the shipment of its 10,000th QSFP28 module to customers.

The 2x50G-PAM4 QSFP28 will operate at a worst case power consumption of 3.5W at 70C case temperature and support KR4 FEC in the host IC. The company is also in development to support a KP4 FEC implementation similar to the FR8 requirements for 8-channel 400G standards.

“Cloud scale and Web 2.0 datacenters are demanding increased volume and lower cost 100G small form factor products and reducing component count is a critical long term solution”, says Sheng Zhang, Chief Scientist at Source Photonics. “We are demonstrating a major step towards the productization of PAM4 technology that will be instrumental in the cost reduction of 100G QSFP28 products and the release of initial 400G products.”
