Monday, December 4, 2017

Samsung cranks out 512-GB Flash for mobiles

Samsung has begun production of the first 512-gigabyte (GB) embedded Universal Flash Storage (eUFS) for next-generation mobile devices. A smartphone with 512GB of flash would be capable of storing approximately 130 4K Ultra HD (3840x2160) video clips of a 10-minute duration.

The new devices stack together eight 64-layer 512Gb V-NAND chips and a controller chip.

Samsung said its new 512GB UFS doubles the density of its previous 48-layer V-NAND-based 256GB eUFS, in the same amount of space as the 256GB package.

Monday, November 27, 2017

Toshiba intros 10 TB HDD for video surveillance

Toshiba America Electronic Components introduced a 10 TB hard drive designed for 24/7 streaming operation scenarios, and is typically used for surveillance digital video recorders (SDVR), surveillance network video recorders (SNVR) and Hybrid SDVR. The 3.5-inch drive is optimized to support up to 64 camera streams. Higher capacity and transfer rates enable support for higher resolution camera streams to meet changing compliance mandates for surveillance data.

The MD06ACA-V Series features 7,200 rpm access performance, and the new 10TB model delivers a 58 percent increase in maximum sustained transfer rate when compared to Toshiba’s prior MD04ABA-V series, pushing it to 237MiB/s3.

Monday, September 25, 2017

Toshiba announces 10TB Enterprise Capacity HDDs

Toshiba America Electronic Components introduced its biggest spinning hard disks yet -- the 10 TB MG06 Series Enterprise Capacity HDD, boasting a 25 percent capacity increase compared to prior generations/

In addition to a heftier capacity, the 10TB MG06 Series features a greater maximum sustained transfer rate, 237 MiB/s2, than the earlier MG05 Series, as well as a 25 percent increase in MTTF3, with a rating of 2.5M hours.

“The volume and value of digital data across organizations of all sizes continue to create opportunities and challenges for CSPs, server and storage vendors, and IT professionals,” said Scott Wright, Director of HDD Product Marketing at Toshiba America Electronic Components, Inc. “Toshiba’s new MG06 Series advances performance and value across a range of Enterprise Capacity HDD models to better align with the diverse needs of systems and solutions for Cloud and Business Critical applications today.”

Tuesday, September 19, 2017

Minio raises $20m for Multi-Cloud Object Storage

Minio, a start-up based in Palo Alto, California, raised $20 million in Series A funding for open source object storage for cloud-native and containerized applications.

Minio has developed an object storage server that enables developers to store unstructured data on any public or private cloud infrastructure, including multi-cloud deployments. The solution lets users build their own Amazon S3-compatible object storage on bare metal, public cloud or existing SAN/NAS storage infrastructure.

Minio reports  over 10M downloads since its general availability in January 2017.

The Series A funding round was jointly led by Dell Technologies Capital, General Catalyst Partners and Nexus Venture Partners, with participation by Intel Capital, AME Cloud and Steve Singh.


Thursday, August 31, 2017

SanDisk packs 400GB into microSD

SanDisk announced the highest capacity microSD card to date: 400GB. This would be sufficient for 40 hours of full HD video. Transfer speed is rated at up to 100 MB/s.

The 400GB SanDisk Ultra microSDXC UHS-I card comes just two years after a 200GB version was announced. MSRP is $250.

“We continue to push technology boundaries and transform the way consumers use their mobile devices,” said Sven Rathjen, vice president, product marketing, Western Digital.

http://www.sandisk.com

Tuesday, August 29, 2017

WD Acquires Tegile for Flash arrays

Western Digital agreed to acquire Tegile, which offers flash and persistent-memory storage solutions for enterprise data center applications. Financial terms were not disclosed.

Tegile, which is based in Newark, California, has been offering flash storage solutions since 2012. The company claims 1,700 customers.

“The Tegile acquisition will fit perfectly in Western Digital’s long-term strategy to deliver high value solutions that address customers’ rapidly evolving storage needs,” said Mike Cordano, president and chief operating officer of Western Digital. “The addition of Tegile’s technology and talented team will advance our goal of solving customers’ most significant challenges in capturing, preserving, transforming and accessing data. We welcome the Tegile team to Western Digital and look forward to working together to enhance our leadership position in enterprise and cloud-based storage.”

http://investor.wdc.com
https://www.tegile.com/


  • Tegile's investors include August Capital, Capricorn Investment Group, Crosscreek Advisors, Meritech, Pine River Capital Management, and Western Digital Capital.

Pure Storage names Charlie Giancarlo as new CEO

Pure Storage annnounced the appointment of Charlie Giancarlo, replacing Scott Dietzen, who will take on the role of Chairman of the Board.

Giancarlo is known for his leadership roles at Cisco, where he previously served as Chief Technology Officer and Chief Development Officer. Since leaving Cisco, he has shared his management experience across Silver Lake Partners’ portfolio, including as Avaya’s Interim CEO, as well as on the boards of Arista, Accenture and ServiceNow.

https://blog.purestorage.com/august-24th-announcement-1/

Monday, August 28, 2017

WD acquires Upthere app for consumer cloud storage

Western Digital has acquired Upthere, a start-up that offers an enhanced cloud storage experience for consumers. Financial terms were not disclosed.

Upthere, which is based in Redwood City, California, offers an app that is "designed to be the single home for all of a user’s photos, videos, documents and music." The Upthere app is available for iPhone, iPad and Android devices, as well as macOS and Windows PCs.

WD said Upthere’s technology and team will augment itss Client Solutions business unit.

In addition, Western Digital announced that Barbara Nelson will lead its Cloud Services business. Ms. Nelson recently joined Western Digital from IronKey, a cloud security business where she was executive vice president and general manager.

http://www.investor.wdc.com

Sunday, August 27, 2017

IBM Offers Data Protection Software

IBM announced a new data protection software with hybrid cloud capabilities that can rapidly move data from on-premises back-end storage to public or private clouds.

IBM said the software is designed to be used by virtual machines (VM) and application administrators. It also provides data clone functionality to support and automate DevOps workflows.

IBM Spectrum Protect Plus is offered for two different deployment options, either as a stand-alone software installed into virtualized environments or as an integrated function with IBM’s Spectrum Protect software, which can be used by large enterprise clients with diverse data protection and availability requirements.

IBM Spectrum Protect Plus also has data protection and monitoring based upon automated Service Level Agreements to provide backup status and support retention compliance.

IBM Spectrum Protect Plus provides data availability using snapshot technology for rapid backup, recovery and data management.

https://www-03.ibm.com/press/us/en/pressrelease/53024.wss

Thursday, August 24, 2017

Flash Memory Summit – big changes in non-volatile memory part 3

Hyperconverged platforms, such as those offered by Nutanix, have proven to be extremely successful in the market because they integrate compute, networking and storage in a single, scale-out box. They are a new way of looking at the old problem of how best to connect these three resources. In a similar fashion, the Open Compute Project, which was launched by Facebook six years ago, set out to rethink how compute, storage and networking could be optimised at the rack level to build hyperscale data centres.

What we’re seeing now, as evidenced by the 2017 Flash Memory Summit in Silicon Valley, is that non-volatile memory is advancing at a faster pace than other storage technologies, and at faster pace than compute (CPUs and GPUs), or networking. Ethernet has continued to progress in either 10X or 4X steps, but recently, these have taken time. In data centres, 10G backbones are common. Carrier backbones typically run utilise 100G links.

These statements were true a year ago – or even two years ago. We see some 400G pluggable transceiver apparently ready for market this year. But will 400G be rapidly adopted in either data centres or carrier networks? For a variety of network engineering reasons, implementing 400G in a network is not as easily done as deploying new SSDs with 4 times the capacity as last year’s model.

More importantly, Samsung Electronics has a ten-year roadmap showing how its 3D NANDs will evolve from 4th generation to 5th, 6th, 7th, 8th, 9th and 10th over the course of a decade.

The company says the physics of the last two generations in this progression have yet to be solved but so far look possible. At this point, it seems likely that this rapid evolution will deliver 2X or 3X capacity improvements every two years of less. On the networking side, we’ve seen the Ethernet Alliance publish an Ethernet Roadmap that envisions a proliferation of new interface speeds. This roadmap predicts terabit speed interfaces by 2020, scaling up to 10 terabits/second by 2030. Storage innovation may be winning this race.

Here are some other interesting observations on the storage market.

Western Digital pushes 3D NAND to 96 layers

Western Digital, which received the Flash Memory Summit ‘Best of Show’ award for its BiCS4 technology, has now pushed its 3D NAND technology to 96 layers of vertical storage capability. This marks several years of continuous improvement. In 2016, WD announced 64-layer 3D NAND after achieving 48-layer 3D NAND in 2015. Last month, the company also announced the development of its first four-bits-per-cell (X4) 3D NAND technology. More layers translate into more capacity.
Toshiba faces uncertainty but moves to 64-layer, triple-level Flash

Toshiba’s semiconductor division has been a state-of-turmoil due to restructuring and likely sale. Various suitors have been suggested and apparently rejected either by the company or the Japanese authorities.  Most recently, Toshiba’s management appears to be nearing a deal to sell the business to a consortium led by Bain Capital, although this too may be at an impasse.  The joint venture with SanDisk (a division of WD) focused on flash memory has become mired in legal disputes. Apparently, Toshiba will not ship its latest generation of 96-layer BiCS modules to SanDisk.
Nevertheless, at Flash Memory Summit, Toshiba America Electronic Components (TAEC) introduced its first enterprise SSDs utilizing the 64-layer,3-bit-per-cell TLC (triple-level cell) technology flash memory: the PM5 12Gbit/s SAS series and the CM5 NVM Express (NVMe) series. Toshiba’s PM5 series will be available in a 2.5-inch form factor in capacities from 400GB to 30.72TB], with endurance options of 1, 3, 5 and 10DWPD (drive writes per day). Toshiba also introduced its own consumer SSDs for PCs and laptops based on the same 64-layer technology. Capacity options include 256GB, 512GB, and 1024GB.

Toshiba is also introducing the first MultiLink SAS architecture, enabling up to 3350MB/s of sequential read and 2720MB/s of sequential write in MultiLink mode and 400,000 random read IOPS in narrow or MultiLink mode.

Mellanox looks to NVMe over Fabrics

Mellanox Technologies is pushing ahead with its BlueField System-on-Chip (SoC) for NVMe over a network fabric. BlueField integrates all the technologies needed to connect NVMe over Fabrics flash arrays. It provides 200 Gb/s of throughput and more than 10 million IOPS in a single SoC device. In addition, an on-board multicore ARM processor subsystem enables flexible programmability that allows vendors to differentiate their software-defined storage appliances with advanced capabilities. The BlueField chip can be used to control and connect All Flash Arrays and Just-a-Bunch-Of-Flash (JBOF) systems to InfiniBand and Ethernet Storage fabrics. The Mellanox SoC combines a programmable multicore CPU, networking, storage, security, and virtualization acceleration engines into a single, highly integrated device. Refence storage platforms are now ready.

“By tightly integrating high-speed networking, programmable ARM cores, PCIe switching, cache, memory management, and smart offload technology all in one chip; the result is improved performance, power consumption, and affordability for flash storage arrays. BlueField is a key part of our Ethernet Storage Fabric solution, which is the most efficient way to network and share high-performance storage,” stated Michael Kagan, CTO of Mellanox.

Seagate revs its Nytro Flash storage

Seagate Technology introduced enhanced versions of two flash technologies to boost performance and capacity for mixed data center workloads. The updated solid-state drives — including the 2 TB Nytro 5000 M.2 non-volatile memory express (NVMe) SSD and the Nytro 3000 Serial Attached SCSI (SAS) SSD — address different segments of the cloud and data center markets. The latest Nytro 3000 SAS SSD offers a dual-port SAS interface to maintain data integrity in the event of an unexpected communication channel loss. Capacity is 15TB, more than four times the capacity of the previous version.

Seagate also previewed plans to offer a 64-terabyte (TB) NVMe add-in card (AIC). This forthcoming product boasts a read speed of 13 gigabytes per second (GB/s) — the fastest and highest-capacity SSD ever demonstrated.

“Large-capacity SSDs are in high demand in hyperscale computing, a market that is growing faster than any other sector,” said Jim Handy, general director of research firm Objective Analysis. “Seagate’s new SSDs, with their high-performance interfaces and high capacities, should find ready acceptance in this market and other data center applications.”

WekaIO, a start-up based in San Jose, California with R&D in Israel, introduced a cloud-native scalable file system that scales to exabytes of data in a single namespace while delivering a big performance boost to applications, processing four times the workload compared to IBM Spectrum Scale measured on Standard Performance Evaluation Corp. (SPEC) SFS 2014. A key innovation is that WekaIO eliminates bottlenecks and storage silos by aggregating local SSDs inside the servers into one logical pool, which is then presented as a single namespace to the host applications. A transparent tiering layer offloads cold data to any S3 or Swift cloud object store for unlimited capacity scaling, under the same single namespace.

In partnership with Intel, WekaIO is now demonstrating a native NVMe-oF system using the new “ruler” form factor for Intel SSDs. The companies said this enables a storage capacity of beyond 1PB in 1U while delivering more than 3 million IOPS.

Tuesday, August 22, 2017

Flash Memory Summit – big changes in non-volatile memory - part 2

Over the past year, we’ve seen that HDD capacity increases have plateaued. Spinning disks have been surpassed in storage capacity by SSDs. Performance comparisons between the two is not even a topic of debate. For CIOs, the deployment of flash storage arrays is easy and offers an immediate boost in IOPs for critical applications. More importantly, all the innovation in new drive development has shifted to flash. We are now seeing many approaches being tried in the market to boost SSD performance even further, to scale up to new drive capacities and new array architectures, to adopt new form factors for better rack-scale integration, and increase manufacturing volume to finally meet market demand.

In the first part of this article, we covered Samsung’s rapid progression with 3-D NAND technology. With the arrival of its 5th generation 3D NAND next year we will see 2.5” SSDs soar into the 128TB range. The company says its on-track for 5 more generations of 3-D NAND in the coming decade. In this second part of the article, we’ll look at innovations from another giant, Intel, which has also set its sights on bringing non-volatile memory technologies to the forefront of server, system and data centre design, as well as developments from Nimbus Data and the Gen-Z consortium.

Intel’s non-volatile memory advancements

Intel began shipping its first SSDs as early as 2008 and has been on a continuous improvement path ever since. In 2010, Intel and Micron Technology entered into a partnership focused on NAND flash memory. In 2015, Intel and Micron announced 3D XPoint technology, which was described as the first new memory category since the introduction of NAND flash in 1989, with promises to be up to 1,000 times faster and up to 1,000 times greater endurance than NAND, while being cheaper than DRAM and non-volatile. Intel then adopted the "Optane" brand for products based on thistechnology, while Micron adopted the QuantX brand. Optane is fundamentally different from NAND and uses a combination of unique Intel memory + storage controllers, Intel interconnect IP, and Intel software.

Introducing the memory ruler

Intel's big news at last week's Flash Memory Summit was its new "ruler" form factor for SSD. Instead of the traditional, 2.5" or 3.5" rectangular box for disk drives, Intel's ruler is a long, thin box designed to slide in to a 1" server chassis, plugging in via a PCIe interface at the end of the ruler. It is a slick design. Apart from looking better, the long, thin shape dissipates heat easier. Intel showed a 1” RU server chassis accommodating 32 of these SSD rulers, creating up to 1 petabyte of storage. Intel could offer Optane SSDs and/or 3D NAND SSDs in this form factor.

It’s been a while since a new storage drive format gained widespread acceptance. Intel will need to bring its new form factor to standardization, perhaps via the Open Compute Project, although this was not confirmed. The ruler design should prove to be particularly useful in hyperscale data centres, where plug-n-play convenience is especially useful when 100s of thousands of servers need to be maintained. Intel also noted that its ruler form factor could be used for plug-in accelerators, perhaps FPGA boards optimized for specific functions. No timeline was given for when the ruler might enter the market.

Intel and Attala Systems also announced an FPGA-based accelerated RDMA over Converged Ethernet (RoCE) networking solution designed to serve as high-performance, composable storage infrastructure with features such as self-learning orchestration and provisioning capabilities. The idea is to create an adaptable storage infrastructure that is essentially an elastic block storage (EBS) solution, accelerated. Attala Systems is a start-up based in San Jose, California that was founded by Sujith Arramreddy, who previously co-founded ServerEngines (acquired by Emulex for $250 million in 2010) and ServerWorks (acquired by Broadcom for $1.4 billion in 2001). Attala's CEO is Taufik Ma, who previously was co-GM of Intel's Server System business unit before leaving for a storage/networking start-up. Nimbus Data sees 500 TB SSDs by 2020

Nimbus Data is a privately-held develop of all-flash arrays based in Irvine, California. The company observes that 40 million nearline/high-capacity HDDs are shipped per year, and all of them use the 3.5” form factor. At Flash Memory Summit, Nimbus Data introduced a software and multiprocessor solution for OEMs developing next-generation solid state drives for data centres. Whereas conventional SSDs are based on a single flash controller, Nimbus ExaDrive is based on a distributed multiprocessor architecture. Inside an ExaDrive-powered SSD, multiple ultra-low power ASICs exclusively handle error correction, while an intelligent flash processor provides wear-leveling and capacity management in software. Nimbus sees an opportunity for its ExaDrive being used in super capacity SSDs that let data centers rip-andreplace HDDs with flash. ExaDrive supports the standard SAS interface and is optimized to fully utilize the volume of the 3.5” form factor.

Nimbus said its ExaDrive is used by Viking Technology and SMART Modular Technologies in 50 TB and 25 TB SSDs for cloud infrastructure, technical computing, and digital content storage. The company predicts that its ExaDrive software-defined architecture will enable SSDs as large as 500 TB by the year 2020, achieving up to 600 petabytes in a single rack. This represents a 50x increase over what is possible with HDDs today. “ExaDrive’s software-defined multiprocessor architecture for SSDs delivers a game-changing leap forward in capacity, density, and energy efficiency that HDDs will never be able to recoup,” stated Thomas Isakovich, CEO and Founder of Nimbus Data. “ExaDrive broadens the appeal of flash memory to tier 2 and nearline use cases, enabling flash to become the dominant data center storage media.”

Gen-Z consortium targets data centres

The Gen-Z Consortium is a vendor-led group that is developing an open systems interconnect with memory semantic access to data and devices via direct-attached, switched or fabric topologies. Its major members include AMD, ARM, Broadcom, Cray, Dell EMC, Hewlett Packard Enterprise, Huawei, IDT, Micron, Samsung, SK hynix, and Xilinx. At this year’s Flash Memory Summit, the group had planned it’s the Gen-Z multi-vendor technology demonstration, connecting compute, memory, and I/O devices. Despite the unfortunate fire at a vendor booth on the opening day of the event, the demo was still able to occur in a nearby meeting room.

The demo showed FPGA-based Gen-Z adapters connecting compute nodes to memory pools through a Gen-Z switch, creating a fabric connecting multiple server vendors and a variety of memory vendors. Such a highperformance and scalable fabric/interconnect could be implemented in future data centres. The demo also featured a scalable prototype connector defined by the Gen-Z Consortium, running at 112 giga-transfers/sec. “We are excited to showcase the first technology demonstration of Gen-Z that includes solutions from multiple member companies, including a variety of servers, memory and I/O devices, all connected with a Gen-Z fabric,” said Kurtis Bowman, President of the Gen-Z Consortium. “The consortium continues to meet the planned development schedule and we expect to see initial Gen-Z products in the 2019-2020 timeframe.”

http://genzconsortium.org/

Thursday, August 17, 2017

Flash Memory Summit – big changes in non-volatile memory - part 1

Can you imagine a 128 TB SAS SSD? It is coming soon from Samsung in the familiar 2.5” disk drive package and destined for the next generation of cloud data centres. Leading companies and start-ups from across the storage industry met at this week's Flash Memory Summit in Santa Clara, California. A key takeaway from the event is that solid state storage continues to improve at a rate much faster than networking technologies. Solid state drives surpassed spinning disks in total capacity some time ago - Samsung announced a 16 TB SDD in August 2015 and currently offers a 32 TB SSD, but prices remain high.



The market is driven by unrelenting demand for flash drives in laptops, desktops and servers, especially in cloud data centres where there has been an uptick in spending over the last few quarters. NAND prices on a $/GB are significantly higher than they were 12 months. According to data from Objective Analysis, contract prices for NAND averaged $0.30 per gigabyte on July 2nd, compared to $0.20 per gigabyte a year ago. Looking at Amazon.com, the street price of a 500 GB SSD is about the same in mid-2017 as last summer. Meanwhile, with higher prices and relentless demand in the current market, the leading manufacturers of 3D NAND are doing quite well. For Samsung Electronics, this translated into very strong revenue and earnings for its June financial report, which predicted that a tight market for DRAM and 3D NAND will continue for the rest of the calendar year.

In a presentation at Flash Memory Summit, Jim Handy of Objective Analysis predicted that NAND prices will remain stable at these rates through mid-2018, but will then suddenly collapse due to a saturation of new supply entering the market. His argument goes that all vendors have begun to ship 3D NAND but only in limited volume due to the complexity of mastering 3D NAND manufacturing. Over time, these complexities are being ironed out, manufacturers will move to add additional layers of stacking and the cost per GB will become cheaper for 3D NAND than for 2D planar NAND. Objective Analysis expects a steep oversupply of 3D NAND by late 2018, even before significant new manufacturing facilities in China come online.

Disruption at Flash Memory Summit

This year’s Flash Memory Summit was disrupted on opening day by a fire in the exhibition area, apparently an electrical issue at one of the vendor stands. Thankfully no one was hurt, but the exhibits were cancelled for the remainder of the event. Conferences and keynotes were the forum for technological disruptions, of which there are plenty in this rapidly evolving segment.

Firstly, Samsung made several important announcements and previewed that massive 128 TB SSD. At a fundamental level, Samsung said its 3D NAND roadmap is progressing on schedule. Last year, Samsung introduced its 4th generation, 64-layer triple-level-cell V-NAND flash memory. This has now gone into production and is being used for products such as the 32TB SSD. Drive capacity and performance are expected to scale up with the upcoming v5 generation of 3D NAND. Samsung has already started work on v6 and v7, with an assumed 18-month interval between each generation. Samsung executives seemed confident they will be able to squeeze at least ten generations out of 3D NAND technology, which provide another decade of continuous improvement if Flash SSD. Beyond that, other non-volatile memory technologies will need to be developed.
Samsung's 1 TB V-NAND chip

Samsung also announced a 1 TB V-NAND chip, slated for commercial production next year, that will enable 2 TB of memory in a single V-NAND package. This is achieved by stacking 16 x 1 TB dies – an advancement the company considers 'one of the most important memory advances of the past decade'.

Samsung is introducing a 16 TB NGSFF (next generation small form factor) SSD that is designed for use in 1U rack servers. Measuring 30.5 x 110 x 4.38 mm, the Samsung NGSFF SSD aims for improved space utilisation and scaling. The company showcased a 1U sample design, codenamed Mission Peak, that pack 36 of the units for a total capacity of 576 TB in the 1 RU appliance. Samsung is looking for partners on this new drive form factor.

In addition, for extreme SSD read/write performance, Samsung introduced its first Z-SSD product, boasting 15 microseconds of read latency time, which is approximately a seventh of the read latency of an NVMe SSD. At the application level, the company estimates its Z-SSDs can reduce system response time by up to 12 fold compared to using NVMe SSDs.

Samsung is also introducing a technology it calls Key Value SSD. Whereas today's SSDs convert object data of widely ranging sizes into data fragments of a specific size called 'blocks', the new Key Value SSD technology allows SSDs to process data without converting it into blocks. Samsung said its Key Value instead assigns a ‘key’, or specific location, to each value, or piece of object data, regardless of its size. The key enables direct addressing of a data location, which in turn enables the storage to be scaled.

Saturday, August 12, 2017

IBM says magnetic tape remains competitive for cold cloud storage

IBM announced a new world record for tape storage density: 201 Gb/in2 (gigabits per square inch) in areal density. This is more than 20 times the areal density used in current state of the art commercial tape drives such as the IBM TS1155 enterprise tape drive. IBM said this breakthrough enables the potential to record up to about 330 terabytes (TB) of uncompressed data* on a single tape cartridge that would fit in the palm of your hand.

The record was achieved on a prototype sputtered magnetic tape developed by Sony Storage Media Solutions.  IBM researchers developed several technologies to make this possible, including: new signal-processing algorithms for the data channel, based on noise-predictive detection principles; a set of advanced servo control technologies that when combined enable head positioning with an accuracy of better than 7 nanometers; a novel low friction tape head technology that permits the use of very smooth tape media.

IBM also noted that the potential exists to continue improving tape storage density at the current pace for many years to come.

“Tape has traditionally been used for video archives, back-up files, replicas for disaster recovery and retention of information on premise, but the industry is also expanding to off-premise applications in the cloud,” said IBM Fellow Evangelos Eleftheriou. “While sputtered tape is expected to cost a little more to manufacture than current commercial tape that uses Barium ferrite (BaFe), the potential for very high capacity will make the cost per TB very attractive, making this technology practical for cold storage in the cloud.”

http://www-03.ibm.com/press/us/en/pressrelease/52904.wss


Wednesday, August 2, 2017

Google picks up the pace in cloud computing

When it comes to the cloud, Google certainly isn't taking a summer holiday. Over the past weeks there have been a string of cloud related developments from Google showing that is very focused, delivering innovative services and perhaps narrowing the considerable market share gap between itself and rivals IBM, Microsoft Azure and Amazon Web Services. There is a new Google cloud data centre in London, a new data transfer service, a new transfer appliance and a new offering for computational drug discovery. And this week came word from Bloomberg that Google is gearing up to launch its first quantum computing cloud services. While the company declined to comment directly about the Bloomberg story it is understood that quantum computing is an area of keen interest for Google.

New London data centre

Customers of Google Cloud Platform (GCP) can use the new region in London (europe-west2) to run applications. Google noted that London is its tenth region, joining the existing European region in Belgium. Future European regions include Frankfurt, the Netherlands and Finland. Google also stated that it is working diligently to address EU data protection requirements. Most recently, Google announced a commitment to GDPR compliance across GCP.

Introducing Google Transfer Appliance

This is a pre-configured solution that offers up to 480TB in 4U or 100TB in 2U of raw data capacity in a single rackmount device. Essentially, it is high-capacity storage server that a customer can install in a corporate data centre. Once the server is full, the customer simply ships the appliance back to Google for transferring the data to Google Cloud Storage. It offers a capacity of up to one-petabyte compressed.

The Google Transfer Appliance is a very practical solution even when massive bandwidth connections are available at both ends. For instance, for customers fortunate enough to possess a 10 Gbit/s connection, a 100TB data store would still take 30 hours to transfer electronically. A 1PB data library would take over 12 days using the same10 Gbit/s connection, and that is assuming no drops in connectivity performance. Google is now offering a 100TB model priced at $300, plus shipping via FedEx (approximately $500) and a 480TB model is priced at $1800, plus shipping (approximately $900). Amazon offers a similar Snowball Edge data migration appliance for migrating large volumes of data to its cloud the old-fashioned way.

Partnership for computational medicine

Under a partnership with Boston -based Silicon Therapeutics, Google recently deployed its INSITE Screening platform on Google Cloud Platform (GCP) to analyse over 10 million commercially available molecular compounds as potential starting materials for next-generation medicines. In one week, it performed over 500 million docking computations to evaluate how a protein responds to a given molecule. Each computation involved a docking program that predicted the preferred orientation of a small molecule to a protein and the associated energetics so it could assess whether it will bind and alter the function of the target protein.

With a combination of Google Compute Engine standard and Preemptible VMs, the partners used up to 16,000 cores, for a total of 3 million core-hours and a cost of about $30,000. Google noted that a final stage of the calculations delivered all-atom molecular dynamics (MD) simulations on the top 1,000 molecules to determine which ones to purchase and experimentally assay for activity.

Pushing ahead with Kubernetes

The recent open source release of Kubernetes 1.7 is now available on Container Engine, Google Cloud Platform’s (GCP) managed container service. The end result is better workload isolation within a cluster, which is a frequently requested security feature in Kubernetes. Google also announced that its Container Engine, which saw more than 10x growth last year, is now available from the following GCP regions:

•   Sydney (australia-southeast1).

•   Singapore (asia-southeast1).

•   Oregon (us-west1).

•   London (europe-west2).

Container engine clusters are already up and running at locations from Iowa to Belgium and Taiwan.

New strategic partnership with Nutanix

Google has formed a strategic partnership with Nutanix to help remove friction from hybrid cloud deployments for enterprises.

Reimagining virtual public clouds at global scale

Integrating cloud resources from different areas of the world no longer requires negotiating and installing a VPN solution from one or more service providers. Google can do it for you using its own global backbone. VPC is private, and with Google VPC customers can get private access to Google services such as storage, big data, analytics or machine learning, without having to give the service a public IP address. Global VPCs are divided into regional subnets that use Google’s private backbone to communicate as needed.

VPC, formerly known as GCP Virtual Networks, offers a privately administered space within Google Cloud Platform (GCP). This means global connectivity across locations and regions, and the elimination of silos across projects and teams.

Further information on Google Cloud Platform is available at the blog here:
:

Monday, May 29, 2017

WD Delivers Solid State Drives with 64-Layer 3D NAND Tech

Western Digital introduced its first client solid state drives built with its 64-layer 3D NAND technology.

“Delivering 64-layer 3D NAND-based SSDs into the PC segment marks a critical step in our ongoing conversion to this new technology, as well as offers long-term benefits for our customers,” said Mike Cordano, president and chief operating officer, Western Digital. “Between our two, strong brands in SanDisk and WD, and their respective loyal customer bases and distribution channels, these advanced SSDs will appeal to a very broad footprint of the computing population that are seeking the benefits of today’s newest technologies.”

The WD Blue 3D NAND SATA SSDs boast an industry-leading 1.75M hours MTTF, as well as the quality backing of WD Functional Integrity Testing Lab (F.I.T. Lab™) certification.  The SanDisk Ultra 3D SSDs are ideal as a drop-in upgrade for existing systems.

The WD Blue 3D NAND SATA SSDs will be available in 250GB, 500GB, 1TB and 2TB capacities in both a traditional 2.5-inch/7mm cased drive as well as a single-sided M.2 2280 form factor. SanDisk Ultra 3D SSDs will be available in 250GB, 500GB, 1TB, and 2TB capacities in a traditional 2.5-inch/7mm cased drive form factor.

https://ww.sandisk.com/home/ssd/ultra-3d-ssd

Wednesday, March 15, 2017

CNEX Targets Next Gen SSD Controllers for Hyperscale

CNEX Labs, a private semiconductor company based in San Jose, California, closed its Series C round of financing led by Microsoft Ventures and joined by existing CNEX investors, bringing total funding to over $60 million to date.

CNEX is developing solid-state storage controllers and software for cloud, hyperscale, and enterprise data centers.

The company said it is working with tier-one data center customers and manufacturers of solid-state storage, including NAND flash and other storage media, to create a ground-up re-design of the traditional SSD controller architecture.

“CNEX is developing the next big innovation for solid-state storage through semiconductor and software solutions,” said Nagraj Kashyap, corporate vice president at Microsoft Ventures. “As data generation grows, so too must storage systems. Our support will help CNEX accelerate its contribution to new breakthroughs in the evolution toward a cloud-first world.”

“We place a high value on the expertise that comes with this commitment from Microsoft Ventures,” said Alan Armstrong, CEO and Co-Founder of CNEX Labs. “The industry sees impressive leadership from Microsoft in shaping a new generation of data centers, and the strategic guidance from Microsoft Ventures will be a key asset to CNEX as we launch our storage products into mass production for the global data center ecosystem.”

Worldwide data generation is expected to leap from four zettabytes per year in 2013 to 40 zettabytes per year by 2020 (one zettabyte is one billion terabytes). The sheer volume, variety, and velocity of data is driving the need for innovation in data center technology to store and deliver this data.

http://www.cnexlabs.com

Tuesday, March 7, 2017

HPE to Acquire Nimble Storage for $1 Billion

Hewlett Packard Enterprise agreed to acquire Nimble Storage, a supplier of predictive all-flash and hybrid-flash storage solutions, for $12.50 per share in cash, representing a net cash purchase price at closing of $1.0 billion. In addition to the purchase price, HPE will assume or pay out Nimble’s $200 million in unvested equity awards.

Nimble offers midrange flash storage solutions featuring an intelligent, predictive analytics engine that assesses performance issues across the full data path, from apps to the array.  In addition, Nimble has recently introduced multicloud storage services that combine the best of on-premises and public cloud storage capabilities for Hybrid IT deployments.  Nimble, which is based in San Jose, California, was founded in 2007 and has approximately 1,300 employees worldwide. The company delivered revenue of $402 million in its most recent fiscal year, up 25 percent year over year.

HPE said Nimble’s predictive flash offerings are complementary to its own scalable midrange to high-end 3PAR solutions and affordable MSA products.  In addition, HPE plans to incorporate Nimble’s InfoSight Predictive Analytics platform across its storage portfolio, which will enable a stronger, simplified support experience for HPE customers.

“Nimble Storage’s portfolio complements and strengthens our current 3PAR products in the high-growth flash storage market and will help us deliver on our vision of making Hybrid IT simple for our customers,” said Meg Whitman, President and CEO, Hewlett Packard Enterprise. “And, this acquisition is exactly aligned with the strategy and capital allocation approach we’ve laid out. We remain focused on high-growth and higher-margin segments of the market.”

“Over 10,000 enterprises are using Nimble Storage because our Predictive Cloud Platform is reliably fast, radically simple, and cloud ready,” said Suresh Vasudevan, CEO at Nimble Storage. “This acquisition validates our technology leadership in flash and in the use of cloud-based predictive analytics.  We’re confident that by combining Nimble Storage’s technology leadership with HPE’s global distribution strength, strong brand, and enterprise relationships, we’re creating expansion opportunities for the combined company.”

http://www.hpe.com

Thursday, March 2, 2017

Hedvig Raises $21.5M for Software-Defined Storage

Hedvig, a start-up based in Santa Clara, California, raised $21.5 million in Series C funding for its software-defined storage solutions.

Hedvig provides software-defined storage for enterprises building private, hybrid, or multi-cloud environments. The Hedvig Distributed Storage Platform consolidates block, file, and object into a single, API-driven platform that keeps pace with ever-growing data needs. Its Universal Data Plane technology forms a distributed, scale-out cluster that transforms commodity servers or cloud computing into a flexible foundation for bare metal, hypervisor, and container infrastructure.

The funding included new investments from Singapore-based EDBI and Hewlett Packard Pathfinder, part of Hewlett Packard Enterprise (HPE). The round also included expanded investments from Atlantic Bridge Ventures, including its Oman Technology Fund, and contributions from existing investors True Ventures and Vertex Ventures. The company has now raised a total of $52 million to date.

“All sectors of enterprise IT are being hit by new demands from the massive wave of emerging digital businesses. It’s a wake-up call for the storage industry and a signal that a flexible, simple software-defined storage solution is needed for primary and secondary storage in the era of cloud,” said Avinash Lakshman, founder and CEO of Hedvig.

http://www.hedviginc.com

Wednesday, February 8, 2017

Toshiba Begins Construction of 3D Flash Memory Fab

Toshiba started construction of a new state-of-the-art semiconductor fabrication and a new Memory R&D center at Yokkaichi Operations in Mie prefecture, Japan, the company’s main memory production base.

Fab 6 will be dedicated to production of Toshiba's 3D BiCS FLASH, which promises significant density improvements over planar NAND Flash memory.


http://www.toshiba.com

Monday, February 6, 2017

WD and Toshiba Produce First 512 Gigabit 64-Layer 3D NAND Chip

Western Digital Corp. announced pilot production of the first 512 Gigabit (Gb) three-bits-per-cell (X3) 64-layer 3D NAND (BICS3) chip in Yokkaichi, Japan, with mass production expected in the second half of 2017.

The company describes the first production as a significant achievement in a nearly three-decades-long legacy of flash memory innovations.

“The launch of the industry’s first 512Gb 64-layer 3D NAND chip is another important stride forward in the advancement of our 3D NAND technology, doubling the density from when we introduced the world’s first 64-layer architecture in July 2016,” said Dr. Siva Sivaram, executive vice president, memory technology, Western Digital. “This is a great addition to our rapidly broadening 3D NAND technology portfolio. It positions us well to continue addressing the increasing demand for storage due to rapid data growth across a wide range of customer retail, mobile and data center applications.”

The 512Gb 64-layer chip was developed jointly with the company’s technology and manufacturing partner Toshiba.

http://www.wdc.com

Western Digital Achieves First 64 Layer 3D NAND


Western Digital has achieved pilot production of 3D NAND technology in 64 layers. The technology, which WD is calling BiCS3, was developed jointly with Toshiba, its manufacturing partner. It will be initially deployed in 256 gigabit capacity and will be available in a range of capacities up to half a terabit on a single chip. WD expects commercial volumes of BiCS3 in the first half of calendar 2017. "The launch of the next generation 3D NAND...
