Tuesday, October 18, 2016

Broadcom Intros OLT Silicon for XGS-PON and NGPON-2

Broadcom introduced PON OLT devices with support for the recently ratified ITU G.9807.1 XGS-PON and G.989 NGPON-2 protocols, speeding time to market for symmetric 10Gbps broadband services.

Broadcom's multi-mode BCM68620 system-on-a-chip (SoC) integrates support for both existing and next-generation fiber technologies under a common application programming interface (API), to enable a unified system software design that can be applied to all PON protocols supported by a system manufacturer. The new support for XGS-PON and NGPON2 fall under this same API umbrella, offering excellent software re-use to existing BCM68620 customers as they easily expand their PON portfolio with line cards dedicated to these new protocols.

Sampling is underway.

“Broadcom heard operators’ need for support of the new XGS-PON and NGPON2 standards in commercial silicon, and OEM requirements for simplified development, and we responded,” said Greg Fischer, senior vice president and general manager, Broadband Carrier Access, Broadcom. “Built on our proven PON OLT technologies, the updated BCM68620 family offers the industry’s only silicon platform with support for all the PON protocols ratified and shipping in volume by operators worldwide.”

http://www.broadcom.com

Wednesday, July 10, 2013

Broadcom's EPON ONU and OLT Chipsets Support DOCSIS Provisioning

Broadcom confirmed that its end-to-end EPON ONU and OLT chipsets and DML software are ready to be deployed in DOCSIS provisioning of EPON (DPoE) 1.0 environments.

Broadcom said the 1G EPON and 10G EPON access technologies offer the bandwidth, scale, and features required to deliver demanding business and mobile backhaul services. CableLabs DPoE 1.0 specification fully supports the DOCSIS provisioning processes.

The company has been collaborating with CableLabs, multi-system operators (MSOs) and industry OEMs on defining the requirements for the DPoE 1.0 specifications.

“The DPoE specifications represent a significant achievement on the part of CableLabs, cable MSOs and industry OEMs to create an open standard that achieves full vendor and equipment interoperability. This will further the growth of the cable industry by meeting the bandwidth needs of business users,” said Greg Fischer, Broadcom Vice President and General Manager for Broadband Carrier Access. “As an early supporter of the technology, Broadcom has devoted significant resources to both the standardization process and our product portfolio to make DPoE technology available today.”

CableLabs recently qualified DPoE 1.0 Systems and ONU products through its certification process.

http://www.broadcom.com/press/release.php?id=s775764

Wednesday, September 19, 2012

Broadcom Powers Next Gen 10G EPON

Broadcom introduced a new family of high-density dual, quad and octal port single-chip 10G-EPON Optical Line Terminals (OLTs) that will pave the way for next-generation FTTX access networks.
The new BCM5553x family offers support for both 10 Gbps (10G) symmetric and asymmetric data rates combined with 1 Gpbs (1G)-EPON co-existence on a single fiber, while enabling 3G/LTE mobile backhaul and enterprise business services on a common fiber access network.

Key Features
  • IEEE 802.3av, SIEPON P1904.1/D3.0, China Telecom 3.0, and Cable Labs DPoE  compliant
  • Simultaneous 10G symmetric and asymmetric operation with 1.25 Gbps/2.5 Gbps co-existence
  • 8x 10G IEEE 803.3av-compatible MACs with integrated 10G and 1G Burst-mode OLT SerDes
  • Supports up to 512 subscribers per 10G port with up to four classes of service per subscriber
  • Network Synchronization support for Mobile Backhaul over PON (1588 v2, ToD/1PPS, SyncE)
  • Support for extended-reach PON up to 100 km
  • Support for DOCSIS Mediation Layer (DML) middleware for Cable MSO applications
The new BCM5553x 10G EPON OLT chips can be matched with Broadcom's BCM88350 family of integrated single-chip traffic manager/packet processors and BCM55030 optical network unit (ONU) SoCs for a complete end-to-end solution set.

Saturday, September 15, 2012

AEPONyX Unveils 40-Channel Metro Ethernet DWDM-PON


AEPONyX will be unveiling the world's first single fiber 40-channel Metro Ethernet Access WDM-PON platform. The AEPONyX platform enables the wholesale of Metro Access and Metro Transport through the cross-connection of Dense and Coarse WDM-PON wavelengths at the Ethernet level. The company claims a reach of 60 km.

AEPONyX's flagship MxC-80 product contains 80 SFP ports in a single 3U carrier class -48V DC shelf, and is designed to enable 40 wirespeed Active Ethernet Passive Optical Network (AEPON) channels. Each AEPON channel contains a DWDM-side outside plant access component and a CWDM-side network-to-network interface (NNI) and enables 40 circuits to be multiplexed onto one outside plant fiber and 16 circuits to be multiplexed onto one NNI fiber.

Francois Menard, CTO & Co-Founder of AEPONyX, explains, "Our customers are welcoming our solution because they can multiplex 40 circuits onto a single fiber, yet retain the robustness of a dedicated port with the full functionality of a Carrier Ethernet network-to-network interface for each circuit they wholesale." Further, they can bridge any customer premise to any datacenter across their metro markets, all from a single location, leveraging an entirely passive 60 km outside plant," he adds.

http://www.aeponyx.com

Tuesday, March 20, 2012

Broadcom Acquires Broadlight for $195 Million

Broadcom confirmed its intention to acquire BroadLight, a leading supplier of network and PON processors, for approximately $195 million, net of cash assumed.


The acquisition of BroadLight further extends Broadcom's presence in the access network.


"Combining BroadLight's PON solutions with the strength of Broadcom's broadband access portfolio will enable us to offer a complete, end-to-end solution for customers — from OLT at the central office to CPE at the home. BroadLight's strong engineering team and broad IP will complement and extend our ability to deliver next-generation access technologies to customers, said Dan Marotta, Executive Vice President and General Manager of Broadcom's Broadband Communications Group.
http://www.broadcom.com
http://www.broadlight.com
  • In October 2011, BroadLight announced commercial availability of standard compliant ITU-T G.987 XGPON OLT and ONT silicon. XGPON supports 10Gbps downstream and 2.5Gbps upstream rates. Broadlight is the first in the market with a commercial standard compliant (ITU-T G.987) XGPON OLT and ONT solution.

Monday, March 19, 2012

Broadcom Boosts DOCSIS Ethernet-over-Coax to 1 Gbps

Broadcom has increased the performance of its DOCSIS-based Ethernet over Coax (EoC) cable architecture to 1 Gbps. The enhanced capability supports China's NGB initiative, led by SARFT, the Chinese government agency overseeing broadcasting.


Broadcom said the gain was achieved by leveraging existing EPON and GPON standards and employing DOCSIS technology as part of a customized "final 100 meter" solution. DOCSIS-based EoC cable architecture is a complete chipset and software solution that includes Coax Media Converter (CMC), DOCSIS 2.0 and 3.0 cable modem, and set-top box (STB) SoC solutions.
http://www.broadcom.com

Broadcom + Broadlight Merger?

TheMarker, an Israeli news website, reported that Broadcom will acquire Broadlight in a deal that could be worth $230 million. Neither company has commented on the report.


Broadlight, which is based in Herzliya, Israel, is a leading supplier of GPON chipsets. It also offers a line of embedded multicore processors. Investors include Azure Capital Partners, Benchmark Capital, Delta Ventures, Israel Seed Partners, Motorola Ventures, Star Ventures and Cipio Partners.
http://www.broadcom.com
http://www.broadlight.com

Wednesday, March 7, 2012

Mindspeed Intros Third-Generation Burst-Mode Laser Driver

Mindspeed Technologies introduced the third generation of its burst-made laser drivers for optical networking units (ONUs) for GEPON GPON. The highly integrated solution features power-saving sleep and current reduction modes and supports data rates to 3.1Gbps in a small 4x4 mm package.


"The M02099 family of burst-mode laser driver chipsets builds on the feature set of our widely deployed M02090 and M02098 drivers, including lower power dual-closed-loop EyeMinder™ technology that delivers real-time monitoring and compensation for laser aging and temperature effects,�? said Gary Shah, vice president of product marketing, high performance analog (HPA) at Mindspeed.
http://www.mindspeed.com

Thursday, December 15, 2011

BinOptics Raises $13.3 Million for Lasers of Photodiodes

BinOptics, a start-up spun out of Cornell University in 2000, closed $13.3 million in new funding for its lasers and monolithically integrated optoelectronic components . The company will use the funding to continue expansion of its product lines and to accelerate development of new products.


Five new investors participated in this round: Advantage Capital Partners, Enhanced Capital Partners, Gefinor Ventures, Onondaga Venture Capital Fund, and Rand Capital. Existing investors ArrowPath Venture Partners, Cayuga Venture Fund, Draper Fisher Jurvetson, and FA Technology Ventures also participated.


BinOptics uses proprietary processes for manufacturing lasers and integrated photonic devices at low cost. In recent years, the company has established a strong global market presence by shipping more than 25 million Fabry-Perot (FP) and DFB lasers in high-growth markets such as EPON and GPON. The company is based in Ithaca, New York. http://www.binoptics.com/

Sunday, December 4, 2011

IEEE Investigates EPON over Coax

The IEEE has launched a study group to investigate a new PHY (Physical Layer) standard for operating the Ethernet Passive Optical Network (EPON) protocol transparently over coaxial distribution networks. The goal would be to use IEEE 802.3 Ethernet specifications to significantly boost and broaden the capabilities of Ethernet in existing access networks.


IEEE 802.3 EPON specifications include symmetric data rates of 1 Gbps and 10 Gbps, as well as asymmetric data rates of 10 Gbps downstream and 1 Gbps upstream.


“Operating EPON transparently over coax is a significant step forward. It will help to transform the industry by greatly simplifying operator networks while simultaneously offering subscribers easy and efficient access to dramatically increased bandwidth,�? said Howard Frazier, chair, IEEE 802.3 EPoC Study Group and senior technical director, Broadcom Corporation. “The ability to leverage existing Ethernet infrastructures and cable plant investments while offering a ten-fold increase in data speeds is revolutionary.�?


http://www.ieee.org

Tuesday, November 1, 2011

Broadcom Spins New EPON OLT System-On-Chip

Broadcom introduced its BCM55524 Quad Port Ethernet Passive Optical Network (EPON) Optical Line Terminal (OLT), packing twice the density and power per port of its existing EPON OLT system-on-a-chip (SoC). The new SoC combines the functionality of up to seven application-specific standard parts (ASSPs) and eliminates seven on-board memory devices, dramatically reducing system costs by up to 50 percent.


The BCM55524 quad OLT is designed to work in tandem with Broadcom's StrataXGS aggregation switch series and is backwards compatible with the existing TK3723 OLT chip. It offers four IEEE 802.3ah-compliant EPON MACs with Broadcom Turbo-EPON support as well as integration of four 1.25 Gbps/2.5 Gbps Burst-mode SerDes and four NNI-side SGMII SerDes. http://www.broadcom.com

Monday, October 17, 2011

Vitesse Hits Milestone in EPON Optical Line Termination Ports

Vitesse Semiconductor has shipped more than five million of its VSC7716 burst-mode transimpedance amplifiers (TIAs) for Ethernet Passive Optical Network (EPON) in Fiber-to-the-X (FTTX) applications.


"The VSC7716 is a field-proven TIA that exceeds IEEE Ethernet PON (EPON or GEPON) 802.3ah requirements, giving customers broad flexibility in FTTX applications," said Richard Interrante, director of product marketing for Vitesse. "The VSC7716's zero reliability failure rate in the field is further testament to the device as an industry benchmark solution."


The company noted that it holds the dominant share in the market for burst-mode EPON TIAs, as Infonetics estimates approximately 5.7 million EPON Optical Line Termination (OLT) ports to be shipped by 2012. http://www.vitesse.com

Sunday, October 2, 2011

BroadLight Releases its XGPON Silicon

BroadLight announced commercial availability of standard compliant ITU-T G.987 XGPON OLT and ONT silicon.


XGPON supports 10Gbps downstream and 2.5Gbps upstream rates. Broadlight is the first in the market with a commercial standard compliant (ITU-T G.987) XGPON OLT and ONT solution.


“XGPON enables carriers a robust continuity of their ITU-T PON networks, meeting their evolving service deployments demands by scaling bandwidth, subscriber count and lowering power consumption profiles,�? says Doron Tal, BroadLight's VP of Business Development and Product Marketing. “We continue executing on our commitment to lead the PON processors market through enabling our customers with XGPON solutions."http://www.broadlight.com

Tuesday, September 20, 2011

Broadband Forum Release Fiber Access Specifications

The Broadband Forum released its BroadbandSuite 5.0, which brings together all its work for fiber access networks.
Specifically, BroadbandSuite 5.0 encompasses a number of architecture, management and market
requirement specifications addressing PON that include:

  • TR-142 Framework for TR-069-enabled PON devices (EPON)

  • TR-155 G-PON ONU Requirements for CPE

  • TR-156 Using G-PON Access in the Context of TR-101

  • TR-167 G-PON-fed TR-101 Ethernet Access Node

  • TR-200 Using EPON in the context of TR-101


Two specifications that are in final approval, which define the test plans for G-PON ONU Conformance:

  • WT-247 G-PON ONU Abstract Test Plan

  • OD- 247 G-PON ONU Conformance Test Plan


It also includes two white papers and a tutorial that provide valuable additional information
and background on G-PON:

  • MR-185 White Paper: Next Generation Broadband Access

  • MR-229 White Paper: Leveraging Standards for Next Generation Broadband Wholesale Access

  • MR-246 G-PON Tutorial


"Fiber rollouts, especially hybrid DSL/PON deployments are growing faster than ever. We expect to see fiber figures continue to rise in our mid-year report due next week. BroadbandSuite 5.0 is a major resource for the industry to facilitate and accelerate the deployment of PON and it paves the way for next generation fiber technologies, including XG-PON1 and beyond," stated Robin Mersh, CEO of the Broadband Forum.
http://www.broadband-forum.org

Monday, September 5, 2011

Mindspeed Introduces Burst-Mode Transimpedance Amplifier for GEPON

Mindspeed Technologies introduced a 1.25 Gbps complement to its 10 Gbps Ethernet Passive Optical Network (10G-EPON) burst-mode receiver chipset that delivers a complete solution for GEPON/10G-EPON optical line termination (OLT) receiver equipment used in central office (CO) locations. The new 1.25 Gbps transimpedance amplifier (TIA) for CO-side OLT equipment can be used with the company's previously announced continuous-mode 1.25 Gbps TIA for subscriber-side Optical Networking Units (ONU) equipment, which creates an end-to-end solution for GEPON applications. Mindspeed also offers a receiver solution for next generation higher-speed 10G-EPON applications, consisting of its 10Gbps burst-mode TIA for OLT equipment. Each of Mindspeed's end-to-end solutions is also complemented by ONU and OLT laser drivers and post amplifiers to create complete solutions on each side of the link.
http://www.mindspeed.com

Monday, July 11, 2011

Qualcomm Atheros Introduces 1 Gbps EPON Chip

Qualcomm Atheros introduced a low power 1 Gbps Ethernet passive optical networking (EPON) chip.


The QCA8829 offers power consumption of less than 200mW for grid applications with Gigabit Ethernet (GE) PHY sleep mode enabled and less than 600mW when running full 1 Gbps throughput with GE PHY enabled. The 76-pin package size fits into a small form-factor pluggable (SFP) optical module, simplifying system design for plug-and-play connection with an Ethernet switch or IP router.


It supports multiple standards, such as those used by cable operators in North America, provisioning for smart grid applications over PON in China, and EPON infrastructures in markets worldwide. Specifically, this support includes the North American DOCSIS Provisioning of Ethernet (DPoE) 1.0 specification, IEEE 802.3ah EPON specification, the China State Grid EPON specification, and the China Telecom (CTC) EPON specification.


Samples of the QCA8829 and reference design kits are available now. Volume shipments will be available in the fourth quarter of 2011. http://www.qca.qualcomm.com

  • In July 2010, Atheros acquired Opulan Technologies, a privately held Chinese fabless semiconductor company specializing in solutions for passive optical networking (PON) and broadband access aggregation (MUX).

Monday, May 30, 2011

Broadcom Develops 1G-EPON SoC

Broadcom unveiled a system-on-a-chip (SoC) solution for the Ethernet Passive Optical Network (EPON) market – China's fastest growing broadband technology.



The new BCM53600 series is the first in a family of highly optimized, 1G to 10G scalable, and fully integrated single chip PON MDU SoCs. The highly integrated 1G-EPON SoC offer TR-101, TR-156, and CTC2.1 specification compliance. It delivers end-to-end quality of service (QoS), classification, filtering, and security. IPv6 support provides a future-proof solution for next generation deployments and service upgrades. Multiple interfaces provide flexibility for a smooth transition to evolving technology and multiple deployment scenarios including VDSL, VoIP, 10G-EPON and GPON.
http://www.broadcom.com

Cortina 's 4th Generation EPON ONU

Cortina Systems unveiled its 4th generation EPON ONU featuring new power saving capabilities compliant with SIEPON's power saving feature and supports the new IEEE Energy Efficient Ethernet standard. The device could be used for home gateways of EPON-enable mobile backhaul, or business Ethernet surfaces.



The single chip EPON ONU offers a 500MHz CPU and multiple embedded memory options, has a flexible architecture that allows it to be used as a SFU (Single Family Unit), IP Voice and Video, HGU (Home Gateway Unit), and MDU (Multi-dwelling Unit). It features a VoIP interface that can support up to 4 instants of conversation. It also supports the IEEE802.3az Energy Efficient Ethernet as well as the SIEPON's power saving mode.



Cortina noted that the new EPON ONU could also be used for mobile backhaul and business connectivity applications as it supports 1PPS/ToD timing synchronization based on China Telecom V2.1 EPON Specification and IEEE 802.1AS. The rich feature set and the low BOM cost make the chip an ideal candidate for a single platform solution for a one-port ONU to a full featured triple play home gateway.



"Carriers are implementing PON as a way to deliver fast optical connections to support end users demand for both high speed bandwidth and advance services," said Rick Li, Vice President Marketing, Cortina Systems. "Not only does the CS803x reduce BOM costs by embedding the memory, it supports IPv4/IPv6 co-existence for seamless migration from IPv4 to advanced IPv6 services and a powerful processor for VoIP service. The CS803x provides a solution for the FTTx industry with leading benchmark of performance over power and cost."http://www.cortina-systems.com

Wednesday, April 13, 2011

Mindspeed Readies 10G-EPON Burst-Mode Receiver Chipset

Mindspeed Technologies is ready to demonstrate a 10 Gigabit Ethernet Passive Optical Network (10G-EPON) burst-mode receiver chipset -- the first such device in the industry, according to the company.



Mindspeed's burst-mode receiver chipset includes its recently announced M02138 10G burst mode dual-rate transimpedance amplifier (TIA) and the company's companion M02142 11.3 Gbps limiting amplifier. Together, the two devices provide a complete, cost-effective solution for 10G-EPON Optical Line Terminals (OLTs), while maintaining backward compatibility with existing GEPON designs.http://www.mindspeed.com

Monday, March 14, 2011

SiTime Launches Low-power, High Frequency Oscillator

SiTime introduced the industry's lowest power high frequency oscillator, which reduces oscillator power consumption by up to 66% and is ideally suited for high performance networking, video, computing and storage applications.



The SiT8004 MEMS-based programmable oscillator features 6.7mA of typical current consumption at 125MHz, which is up to 66% lower than that of a standard crystal oscillator. In addition to supporting any frequency between 125 MHz and 150 MHz, it is also available in popular, pre-configured options such as:

  • 125 MHz and 125.00375 MHz for GPON, EPON and Gigabit Ethernet


  • 133 MHz and 133.33333 MHz for MEMORY (DDR) and PCI


  • 148.5 MHz and 148.35164 MHz for HDMI and Pixel clocks


  • 150 MHz for SATA/SAS


"Reducing energy usage is a key goal of electronics manufacturers," said Piyush Sevalia, vice president of marketing for SiTime. "Typically, quartz oscillator suppliers do not have analog circuit expertise as they buy their oscillator die from semiconductor providers. Therefore, they have not been able to deliver low power devices for high frequency applications. SiTime uniquely has both resonator and analog circuit expertise, enabling us to integrate and deliver compelling features to our customers. The SiT8004 is an excellent example of this expertise: not only does it reduce oscillator power consumption by up to 66%, but it is also a drop-in replacement for quartz oscillators, which allows system vendors to reduce energy usage with zero design effort."http://www.sitime.com
