Thursday, March 22, 2018

IEEE Publishes IEEE 802.3cc-2017 25 Gb/s Ethernet Standard

IEEE announced the publishing and availability of its 802.3cc-2017—Standard for Ethernet Amendment: Physical Layer and Management Parameters for Serial 25 Gb/s Ethernet Operation Over Single-Mode Fiber.

The new amendment to IEEE 802.3 addresses the growing need for increased Ethernet speeds for enterprise, campus and metro Ethernet speeds exceeding 10 Gb/s, and that can support reaches up to 10 and 40 kilometers over single-mode fiber (SMF).

IEEE 802.3cc supports efficient Ethernet operation and defines single-lane 25 Gb/s PHYs for operation over single-mode fiber with lengths up to 10 km and 40 km. IEEE 802.3cc addresses the requirement in metropolitan networks, where the core operates at 100 Gb/s, for tributary feeds at rates higher than 10 Gb/s. By enabling extended 25 Gb/s reaches, IEEE 802.3cc matches the per-lane rate of several 100 Gb/s PMDs currently used in these networks.

“IEEE 802.3cc provides network operators a cost-effective upgrade path to 25 Gb/s that minimizes network design, installation and maintenance costs by preserving current network architecture, management, and software,” said David Lewis, chair, IEEE 802.3cc 25 Gb/s Ethernet over Single-Mode Fiber Task Force. “The work of the IEEE 802.3cc 25 Gb/s Ethernet over Single-Mode Fiber Task Force has demonstrated how responding quickly to industry demand for greater energy-efficient Ethernet capabilities can be achieved in a manner that can reduce both operational costs, and the environmental footprint of network upgrades.”

Monday, March 12, 2018

Broadcom’s Terabit Monterey Chip extends Ethernet to LTE and 5G Radios

Broadcom introduced a terabit-class Ethernet switching chip designed for high-capacity cellular fronthaul networks.

The Broadcom Monterey Ethernet switch (BCM56670) targets Ethernet-based 5G radios and while also supporting existing CPRI-based radios.

It supports the IEEE’s new 802.1CM (Time-Sensitive Networking for Fronthaul) standard, which provides an Ethernet synchronization solution, CPRI-to-Ethernet bridging, and nanosecond-scale jitter and delay control.

IEEE 802.1CM specifies how to carry cellular radio traffic over Ethernet, It relies on pre-emption, Synchronous Ethernet, and the 1588 Precision Timing specification.

Broadcom said its Monterey silicon offers an order-of-magnitude increase in synchronization accuracy by moving time stampers from Ethernet MAC to SerDes I/O, exceeding 3GPP, IEEE, and ITU-T specifications for 4G & 5G networks.

Monterey Ethernet switch key attributes:

  • Transports CPRI across standard Ethernet
  • Enables cellular-system designers to leverage the merchant-silicon-based Ethernet ecosystem
  • Connects directly to new Ethernet-based radios and installed CPRI-based radios
  • Terabit-class capacity to meet the 10x increase in capacity needed by 5G networks
  • Serves as a critical component in building mobile-edge computing platforms
  • Hardware support for key 5G requirements, including nanosecond-scale synchronization

“We are very pleased to announce another ground-breaking solution that addresses fundamental problems and opens a new, major market for our switching products,” said Ram Velaga, vice present and general manager, Switch Products at Broadcom. “The Monterey Ethernet switch is an excellent example of Broadcom’s deep commitment to 5G innovation and strategic R&D investment.”
Sampling is underway.

Wednesday, March 7, 2018

Broadcom's Jericho2 switch-routing chip boasts 10 Tbps capacity

Broadcom announced commercial availability of its Jericho2 and FE9600 chips, the next generation of its StrataDNX family of system-on-chip (SoC) Switch-Routers.

The Jericho2 silicon boasts 10 Terabits per second of Switch-Router performance and is designed for high-density, industry standard 400GbE, 200GbE, and 100GbE interfaces. Key features include the company's "Elastic Pipe" packet processing, along with large-scale buffering with integrated High Bandwidth Memory (HBM).

The new device is shipping within 24 months from its predecessor Jericho+., Jericho2 delivers 5X higher bandwidth at 70% lower power per gigabit.

In addition to Jericho2, Broadcom is shipping FE9600, the new fabric switch device with 192 links of the industry's best performing and longest-reach 50G PAM-4 SerDes. This device offers 9.6 Terabits per second fabric capacity, a delivers 50% reduction in power per gigabit compared to its predecessor FE3600.

“The Jericho franchise is the industry’s most innovative and scalable silicon used today in various Switch-Routers by leading carriers,” said Ram Velaga, Broadcom senior vice president and general manager, Switch Products. “I am thrilled with the 5X increase in performance Jericho2 was able to achieve over a single generation. Jericho2 will accelerate the transition of carrier-grade networks to merchant silicon-based systems with best-in-class cost/performance.”

Monday, March 5, 2018

IDC: Modest growth for Ethernet switch and router market

The worldwide Ethernet switch market (Layer 2/3) recorded $6.9 billion in revenue in the fourth quarter of 2017 (4Q17), an increase of 3.2% year over year, according to IDC's newly updated Worldwide Quarterly Ethernet Switch Tracker and Worldwide Quarterly Router Tracker, and reached more than $25.7 billion in revenue for the full year 2017, an increase of 5.4% over 2016.

IDC calculates that the worldwide total enterprise and service provider (SP) router market recorded just under $4.0 billion in revenue in 4Q17, increasing 2.4% on a year-over-year basis. For the full year 2017, the router market finished at $15.2 billion, an increase of 4.0% over 2016.

"The Ethernet switch market continues to exhibit healthy growth, driven by network refreshes and investments in the fast-growing campus and datacenter segments. In the combined service provider and enterprise router market, vendor dynamics are beginning to shift as end users look to capitalize on higher-speed cloud connectivity," said Petr Jirovsky, research manager, Worldwide Networking Trackers.

IDC notes that 100Gb Ethernet switch revenue continues to grow rapidly as adoption by hyperscale cloud providers and large enterprises accelerates.

Some highlights:

  • 100Gb shipments reached more than 1.3 million ports and $661 million in revenue in 4Q17.
  • 100Gb now accounts for 9.6% of total market revenue, up from just 4.8% in the same quarter a year ago.
  • 25Gb/50Gb Ethernet switch products continue to gain traction. Shipments exceeded 1 million ports with $124 million in revenue in 4Q17.
  • Growth in 25Gb, 50Gb, 100Gb continue to negatively impact the 40Gb segment. 40Gb port shipments decreased 6.9% year over year and revenue was down 11.2% for all of 2017.
  • The 10Gb market continues to see healthy growth but pricing pressure is holding back revenue increases.
  • 10Gb shipments in 4Q17 grew 37.2% year over year while revenues decreased 2.7%. Meanwhile, 1Gb remains the primary connectivity technology for enterprise campus and branch deployments, driving 1Gb port shipments to 112.6 million in 4Q17, growing 5.4% year over year with market share remaining steady at 66.7% of all ports shipped.

Thursday, February 22, 2018

CenturyLink vaults to top of U.S. Ethernet LEADERBOARD

CenturyLink has captured the #1 spot on Vertical Systems Group's latest LEADERBOARD of U.S. Ethernet market leaders. It is the first time a provider other than AT&T has led the benchmark ranking since 2005.

Seven companies achieved LEADERBOARD status for 2017 (in rank order based on retail port share): CenturyLink, AT&T, Verizon, Spectrum Enterprise, Comcast, Windstream and Cox.

CenturyLink’s advance was driven by its November merger with Level 3, along with continued growth in Ethernet ports for both companies. Previously, Level 3 ranked second to AT&T and CenturyLink ranked fifth on the Mid-2017 U.S. Ethernet LEADERBOARD.

To qualify for the LEADERBOARD, network providers must have four percent (4%) or more of the U.S. Ethernet services market. Shares are measured by the number of billable retail customer ports in service as tracked by Vertical Systems Group.

“In addition to the shakeup at the top of the LEADERBOARD, U.S. Ethernet installations exceeded the milestone of one million ports in 2017,” said Rick Malone, principal of Vertical Systems Group. “Overall, the fastest growing Ethernet deployments were driven by higher speed cloud connectivity and IP VPN access. Service providers cite price compression as a continuing challenge, as well as delayed network purchase decisions due to SD-WAN evaluations.”

Highlights of Vertical’s year-end 2017 U.S. Ethernet market share analysis:

  • The U.S. retail Ethernet port base grew 13% in 2017 and finished the year with more than one million ports.
  • Seven Ethernet providers qualified for the 2017 LEADERBOARD, as compared to nine in 2016. The two company exits were XO (acquired by Verizon) and Level 3 (merged with CenturyLink). As a result, the U.S. LEADERBOARD has no companies from the Competitive Provider segment for the first time.
  • Four Incumbent Carriers (CenturyLink, AT&T, Verizon, Windstream) and three Cable MSOs (Spectrum Enterprise, Comcast, Cox) are represented on the latest LEADERBOARD.
  • Comcast had the highest organic growth rate of the LEADERBOARD companies in 2017, growing its base of Ethernet ports appreciably without an acquisition.
  • Six Ethernet providers qualified for the 2017 Challenge Tier, as compared to four in 2016. New entrants Frontier and GTT moved up into the Challenge Tier from the Market Player tier based in part on acquisitions of Ethernet assets. These companies join Altice USA, Cogent, Sprint and Zayo.
  • Each of the seven LEADERBOARD companies has attained MEF CE 2.0 Ethernet services certification, and each employs MEF Carrier Ethernet Certified Professionals (MEF-CECPs). Spectrum Enterprise leads with more than 800 MEF-CECPs, followed by CenturyLink with greater than 500. Companies on the U.S. Ethernet LEADERBOARD plus Challenge Tier employ more than one-third of the 5,500+ MEF-CECPs worldwide.

In addition to the roster of LEADERBOARD providers, all other companies selling Ethernet services in the U.S. are segmented into two tiers as measured by port share. The first or Challenge Tier includes providers with between 1% and 4% share of the U.S. retail Ethernet market. For year-end 2017, the following six companies attained a position in the Challenge Tier (in alphabetical order): Altice USA, Cogent, Frontier, GTT, Sprint and Zayo.

The second or Market Player tier includes all providers with port share below 1%. Companies in the Market Player tier include the following providers (in alphabetical order): Alaska Communications, Alpheus Communications, American Telesis, Birch Communications, BT Global Services, Cincinnati Bell, Consolidated Communications, Crowne Castle, DQE Communications, Expedient, FiberLight, FirstLight, Global Cloud Xchange, Great Plains Communications, Hawaiian Telecom, Logix Fiber Networks, LS Networks, Lumos Networks, Masergy, MegaPath, Midco, NTT America, Orange Business, RCN Business, Tata, TDS Telecom, Telstra, TPx Communications, Unite Private Networks, US Signal, WOW!Business and other companies selling retail Ethernet services in the U.S. market.

Wednesday, January 31, 2018

Broadcom brings new Ethernet programmability with open source logical table software

Broadcom is introducing a new approach to Ethernet switch configuration that makes use of open source software to allow network hard vendors, OS vendors and even enterprise network managers to monitor, analyze, and provision switch resources through a standard software interface.

This capability is enabled by a new Software Development Kit Logical Table (SDKLT) for Broadcom switch ASICs that leverages table-based programming, where all the device physical resources such as MAC Address Tables, L3 route tables, TCAMs, etc. are exposed as logical tables. Device-specific information is stored in databases and not embedded in the APIs. Device-specific behavior is managed by logical tables through a small set of APIs. Broadcom said this approach introduces new ways to monitor, analyze and provision switch resources, all through industry standard automation tools. The company is making this logical table programmability available as an open source SDK.

Broadcom's first open source offering of the SDKLT is for BCM56960 Tomahawk switch, which is widely used in data center top-of-rack (TOR) switches. The SDKLT open source code is posted on GitHub. The open source code and the Logical Table APIs are released under Apache 2.0 license. The software is designed for High Availability (HA) including support for Soft Error Recovery, Warmboot, and In Service Upgrades.

“The SDKLT brings a fresh, state-of- the-art software development approach to the broader community of network software developers where they can now fully and directly control and monitor the rich switch feature set optimized for SDN and cloud use cases,” said Ram Velaga, senior vice president and general manager of switching products.

Monday, January 29, 2018

Crehan: 400GbE to drive most data center Ethernet switch bandwidth by 2022

Expect to see initial shipments of 400 gigabit Ethernet (GbE) switches this year and look for exponential growth ahead. The 400 GbE technology will drive the majority of data center Ethernet switch bandwidth by 2022, according to a newly published Data Center Switch Long-Range Forecast Report from Crehan Research Inc.

“Beginning with high-density 100GbE systems, we entered a new era of much faster data center switch upgrades, and that trend is predicted to continue with 400GbE,” said Seamus Crehan, president of Crehan Research.  "With its expected market-leading price per gigabit and no foreseeable shortage of demand for higher-speed networking capacity in cloud data centers, 400GbE should surpass a million ports shipped in less time than it took 100GbE to reach that threshold.”

In addition to a strong ramp of 400GbE, Crehan’s report predicts that:

  • 400GbE data center switches will offer a bandwidth discount over lower speed switches during the initial year of shipments
  • 400GbE adoption will be further bolstered by the arrival of 100G-PAM4 SerDes, likely in the 2020 timeframe, thus reducing the number of lanes required to achieve 400GbE by half – from 8*50 to 4*100 – and further lessening the cost and power of these data center switches
  • 100GbE shipments will surpass 40GbE shipments during 2018, just three years after the initial shipments of high-density 100GbE data center switch systems
  • The overall market average selling price per port for data center switching will remain relatively stable, driven by the adoption of higher-speed switches

Monday, January 22, 2018

AT&T expands Switched Ethernet Service in Equinix data centers

AT&T will make its Switched Ethernet Service with Network on Demand available to businesses in Equinix International Business Exchange (IBX) data centers under Under an expanded partnership announced by the firms. The service is currently available at Equinix IBX data centers in the following metro areas: Atlanta, Chicago, Dallas, Los Angeles, Miami, Silicon Valley and more.

AT&T and Equinix said the new AT&T Network on Demand service offered at Equinix enables intelligence across cloud service providers, and brings connectivity and expanded interconnection opportunities closer to where businesses operate.

“A dynamic network can differentiate a company. This is a critical move for many customers as they continue on their digital transformation and look to adopt technologies that require optimal speed and performance,” said Roman Pacewicz, chief product officer, AT&T Business. “Our work with Equinix lets us deliver the physical infrastructure and network connectivity options to support our customers’ evolving business needs.”

Tuesday, January 16, 2018

UNH-IOL tests 1000BASE-T1 in automotive Ethernet

The University of New Hampshire InterOperability Laboratory (UNH-IOL) is adding two new services to its Automotive Ethernet Test Services menu:

  • 1000BASE-T1 Physical Medium Attachment (PMA) sublayer testing and
  • 100BASE-T1 interoperability testing.

“With the standardization of single-pair Gigabit Ethernet (1000BASE-T1) coming two years ago, chip manufacturers and silicon vendors are now tasked with ensuring their offerings can provide reliable and resilient functionality in environments where noise and electromagnetic interference concerns must be thoroughly addressed,” said Curtis Donahue, Senior Manager, Ethernet Technologies UNH-IOL. “Ethernet is established as the base solution for advanced automotive applications, such as self-driving cars and assuring reliable network interconnectivity. Launching the 1000BASE-T1 test service at the UNH-IOL sets the stage for allowing silicon vendors and Tier 1 automotive suppliers to streamline product developments and advance technologies that will help drive further innovation in the industry.”

Monday, January 15, 2018

Renewed growth in servers and Ethernet switching

There are renewed signs of strength in several key industry segments, including servers and switches.
You might think that all of the action is concentrated in public clouds and that the only vendors benefitting from this shift are white box vendors from Asia. But that is not what the Q3 2017 data shows. Certainly, the public cloud is growing by leaps and bounds and ODMs from China and Taiwan are shipping in ever greater volume.
However, a few of the top name brand server vendors, especially Dell, IBM and Cisco (to a lesser extent) are finding renewed growth beyond the handful of hyperscale public cloud projects. This seems to indicate that large corporate data centers are entering a refresh cycle. Intel continues to dominate this sector. Demand for x86 servers increased 20.4% in 3Q17 with $15.4 billion in revenues. Non-x86 servers grew 15.1% year over year to $1.5 billion.
IDC finds that vendor revenue in the worldwide server market increased 19.9% year over year to $17.0 billion in 3Q17.
Top 5 Companies, Worldwide Server Vendor Revenue, Market Share, and Growth, Third Quarter of 2017 (Revenues are in Millions)

3Q17 Revenue

3Q17 Market Share

3Q16 Revenue

3Q16 Market Share

3Q17/3Q16 Revenue Growth
1. HPE / New H3C Group





2. Dell Inc





3. IBM





3. Cisco





5. Lenovo





ODM Direct















IDC's Worldwide Quarterly Server Tracker, November 2017

It is good to see this growth is shared by major geographies. IDC breaks down the growth rate as follows:
Server shipment revenue growth (yoy)
·         Asia/Pacific (excluding Japan and China) +30.6%
·         China +23.9%
·         Japan +8.5%
·         U.S. +19.7%
·         EMEA + 19.5%
·         Canada +14.5%
·         Latin America +2.4%.
Servers require switches, so it is not surprising to see this market segment growing in step with the server shipments.

Dell’Oro Group recently reported that Ethernet Switch – Layer 2+3 market revenue reached an all-time record in 3Q17, posting the highest year-over-year growth in five years. The positive results were driven by both campus switching and data centre switching. Cisco did will with its new Catalyst 9K switches and Intent-based networking paradigm. Arista did exceptionally well as evidenced by its most current quarterly financial report and despite the ongoing legal battle with Cisco.

“We are starting to see signs for recovery in the Campus Switching market,” said Sameh Boujelbene, Senior Director at Dell’Oro Group. “Softness in campus switching has been weighing on the Ethernet Switch market over the past two years. It has been outweighing strength in Data Center switching until now as Cisco and HPE captured most of the growth in North American and European campus switching markets during the quarter, while Chinese market remained dominated by Huawei and H3C,” stated Boujelbene.

IDC also reported a strong Q3 for the worldwide Ethernet switch market (Layer 2/3). The IDC figures show $6.75 billion in revenue in the third quarter of 2017 (3Q17), an increase of 7.4% year over year.

Monday, October 9, 2017

Aquantia files for IPO

Aquantia Corp., which supplies high-speed Ethernet silicon for data centres, enterprise infrastructure and client connectivity, filed an S-1 registration statement with the U.S. Securities and Exchange Commission relating to a proposed initial public offering of shares of its common stock.

Aquantia has applied to list its common stock on the New York Stock Exchange under the ticker symbol “AQ.”

Morgan Stanley & Co. LLC, Barclays Capital Inc., and Deutsche Bank Securities are acting as bookrunners for the proposed offering. Needham & Company and Raymond James are acting as co-managers.

  • Aquantia is based in Fremont, California.
  • Aquantia is headed by Faraj Aalaei, CEO and Chairman of the Board. Previously, Aalaei served as Chief Executive Officer and was one of the founders of Centillium Communications, a semiconductor solutions company.
